trochoidal

Examples

Videos

  • trochoidal pattern
  • CAM Programming Tip: Trochoidal Milling Sandvik Coromant Trochoidal Milling is a secure, productive method for removing material in scallops and pockets. This programming technique uses the low radial engagement of high-speed machining while maintaining a constant feed per tooth. Huge benefits, including improved tool life, can be seen in Titanium and Inconel where the chip is particularly hard to break.
  • Grinding Technology Trochoidal Milling Grinding Technology recomends Trochoidal milling, a very efficient way to produce a slot is to use the Trochoid method. A constant circular interpolation movement is used in order to produce the required slot width.
  • Trochoidal milled clamps.WMV Milling 4 clamp blocks using a combination of Trochoidal and other milling. Used CamBam to write GCode. The steel block is 40mm deep by 75mm wide 260mm long. The trochoidal milling is at the start were I am cutting the side taking 10mm deep 1 mm bite 14mm cutter moving at 2 metrepm.
  • Trochoidal machining on Tormach PCNC 1100 Trochoidal tool path generated by OneCNC XR, machined on Tormach PCNC 1100 with BT30 Lyndex SK holder and RobbJack 3/8" 3 flute aluminium specific end mill. 54IPM, 4500RPM, ~.05 DOC, 80% WOC
  • Trochoidal milling with a broken end mill.WMV I wanted to prove a point so I used a endmill that had the tip smashed off it to mill a 16mm thick plate 200mm wide. I wrote the code using CamBam's new Trochoidal milling plugin. Its brilliant well worth a try
  • RobbJack High Speed Hard Metal Trochoidal Machining 54 HRc Hardened H13 RobbJack High Speed Hard Metal Trochoidal Machining 54 HRc H13 Hardened Die/Mold material. Using a RobbJack HM-602-16 1/2" diameter 6 flute solid carbide end mill at 125 inches per minute without coolant
  • Iscar ChatterFree Solid Carbide Endmill - Slotting using X5 Peel Mill (Trochoidal "D-Cutting" ) Tool: ECI-E5L500-1.25C500CF (5622529) Holder: CAT40 ER32 SHORT B (4503446) Collet: ER32 EX. .500 (4500231) TIR: .0002 Material: ASTM A514 Grade H steel ---------------------------------------------------------------- SFM: 800 RPM: 6112 IPT: .005" IPR: .025" IPM: 152.8 Axial: 1.200" Radial: 5% (.025") Coolant: Dry Cubes: 4.584 ---------------------------------------------------------------- Programmed using MasterCam X5 Peel Mill.
  • Solid Carbide Rough Fin End Mill Trochoidal:Channel Milling 4140 Steel Tool - RoughFin-Round Solid Carbide End Mill Operation #1 -- Trochoidal Milling Material - 4140 Diameter -- 0.500 SFM -- 600 Y Step Over - 010 RPM - 4584 IPM - 110 APT -- 0.006 WOC -- 1.500 Operation #2 -- Channeling Material - 4140 Diameter -- 0.500 SFM -- 250 RPM - 1910 IPM - 16 APT -- 0.002 WOC -- 0.500 DOC -- 0.750
  • Trochoidal Turning in Pro/NC - Creo Elements/Pro 5.0 After some months investigating solutions I learned a lot about other CAM systems and how they do things. I also learned some nasty marketing tactics employed by CAx vendors and that sometimes the things are wrapped with a nice cover but in the core they are all alike. That being said, I created a small video showing Creo Elements/Pro 5 profile turning toolpaths applied in a complex groove so that you can get the so called "Trochoidal Turning" effect such as shown in Unigraphics NX and Sandvik video. Please check this out at Sandvik website: qstream- This video shows how to make this in Pro/NC or Creo Elements/Pro. It can be done in all Pro/NC versions as well. "Trochoidal Turning" in Siemens NX is NOT a dedicated toolpath as it seems but rather a series of profiles offseted with reversed lead in / lead out moves / cut directions. Enjoy it! Daniel
  • Top view of Trochoidal milling clamps.WMV This is a view of the path the cutting is taking. The cutter here is going 14mm deep 1mm bites.
  • Trochoidal Milling of a plate.WMV The GCode was written with CamBam The first cut was done by drawing the profile of the cut path then doing a "Array Copy" then using engrave and selecting each path in the order you want them cut. The centre sprial path was designed by using the new CamBam "Cad Extra" Plugin to create a spiral.
  • Trochoidal milling with CamBam Showing Cambam being used for Trochoidal milling at 1600mm per minute cutting 20mm plate full depth, 1mm bite with each swing 30mm wide. 14mm endmill rpm at 2400.
  • Trochoidal Slot Cutting of 304 Stainless Steel on Tormach Cutting a slot in 304 stainless steel using a trochoidal tool path on a Tormach PCNC 1100 (Series 2). This video was recorded during feed/speed testing prior to the purchase of G Wizard. Here are the cut details: Cutter: .250" diameter carbide, TiCN coated Slot width: .400" Width of cut: .025" Depth of cut: .080" Feed: 30 ipm Speed: 4000 rpm Turns out my guess at 304 stainless feeds and speeds was wrong and I ended up dulling and then breaking the end mills very quickly. G Wizard was then purchased, but I haven't gone back to try more 304 stainless.
  • DIY CNC Mill Trochoidal cutting 7075 Aluminium billet Hafco HM-30 DIY CNC Mill Trochoidal cutting pattern 25 mm (1 inch) 7075 T651 Aluminium billet DIY 3 axis CNC converted RF 30 clone Mach 3 CNC 2 hp 3 phase 4 pole (10Nm) Rpm: 2080 (max for this machine) Feedrate: 1240 mm/min 20mm 4 tooth solid carbide cutter DOC: 9 mm WOC: 0.2 to start - then 0.5 mm
  • Trochoidal Channel Roughing - High-Speed Roughing Between Walls 5-Axis Trochoidal Channel Roughing is a high-speed roughing cycle that maintains a constant cutter load to remove material in a channel bounded by two walls
  • Trochoidal waves There are three basic types of waves: longitudinal (like sound, and seismic P-waves), transverse (like light, and seismic S-waves), and trochoidal (like surface waves on water)
  • Tips film: Trochoidal milling machining For better tool life, secure machining process machining predictability
  • Iscar ChatterFree Trochoidal Machining 316 SS
  • CNC trochoidal milling-machining CNC - 2 to 5 axis milling machining from WorkNC, Sescoi CAD/CAM software. Trochoidal milling machining. www.workncg3.com
  • CAM Programming Tip: Trochoidal Turning Sandvik Coromant Trochoidal Turning is a secure and productive method for removing material in deep slots and grooves. This programming technique uses a roll into cut approach to reduce engagement on the insert. Results include tremendous tool life increases, improved chip control and increased productivity.
  • CNC trochoidal milling-machining CNC - 2 to 5 axis milling machining from WorkNC, Sescoi CAD/CAM software. Trochoidal milling machining. www.workncg3.com
  • Trochoidal miling test run for CamBam.WMV I designed a part to help in the development of CAmBam to do trochoidal milling. As can be seen the shape makes the loads on the cutter harder during normal milling. Its a 14mm carbide endmill cutting full depth in a 16mm steel plate, it is 200mm wide by 100 depth and at times the cutter is cutting at 2m per minute. The cutter rpm is 2400 and the starting weight of the plate is 2.4kg the finished weight is 600 grms. Current machine time is 18minute but expect to be able to get it down to 14 minutes in the near future.
  • Mastercam's trochoidal milling Here we have a reasonably fast oscillating/trochoidal toolpath demonstration. The cutter being used is a 2-flute half-inch HSS endmill. For better results use a carbide endmill, that way you can run a spectacular depth of cut with the same speed-feed ratio. The programmed speeds-feeds were 49.6-inch/minute @ 4966-RPM. I increased it at the machine control to 6455-RPM then bumped the feeds up to 163.87-inch/minute. The cutter could go deeper if needed, but the pocket parameters required two layers before finishing the depth, so I truncated it down to a more conservative amount. The best way to figure out what works is to try it!
  • CNC hard material trochoidal milling-machining CNC - 2 to 5 axis milling machining from WorkNC, Sescoi CAD/CAM software. Hard material trochoidal milling-roughing. www.workncg3.com
  • Hexapode : usinage trochoidal et orbital usinage trochoidal et orbital ( hexapode , UGV , CMW , axes , parallele , usinage , robot )
  • CamBam trochoidal testing Trying out CamBams trochoidal abilities Don't remember the rpms, but around 5000 (3300 in mach3 isn't correct) 6mm carbide end mill from ctctools
  • Trochoidal milling A Seco solid carbide endmill demonstrate high productivity in trochoidal milling of alloy steel. Learn more at
  • High Speed Trochoidal Machining Cutting slots with a 3/16" Emuge Rougher/Finisher endmill. Machining time for the process was about 5 times faster than standard carbide endmills.
  • Cnc Programming Slot ( with trochoidal method) Software for programming cnc machine, no cad skill required , parameter based system.
  • Tormach PCNC 1100 - Trochoidal Milling of Prototype A prototype being cut from 6061 aluminum using trochoidal tool paths to start the center hole,
  • Trochoidal-Milling-316-Stainless-Steel.mov 1/2" Endmill with vaiable helix, variable pitch. Axial depth of cut = 1.0 inch / radial DOC = .100 max. Base feedrate = 80 IPM / RPM = 3500.
  • Trochoidal Milling using CamBam This pocket is into 16mm thick steel plate. I used CamBam to write the program in a way that enable the cutting to be Trochidal. For the main cutting I was running at 1600mm per minute 16mm deep. You can hear a scream when the cutter slipped due to me not getting it right a couple of times.
  • High productive Sandvik Coromant trochoidal milling
  • Solid Carbide Variable Pitch End Mill Trochoidal:Channel Milling 4140 Steel Tool - Stedi-Round Variable-Pitch End Mill Operation #1 -- Trochoidal Milling Material - 4140 Diameter -- 0.500 SFM -- 600 Y Step Over - 010 RPM - 4584 IPM - 110 APT -- 0.006 WOC -- 1.500 Operation #2 -- Channeling Material - 4140 Diameter -- 0.500 SFM -- 250 RPM - 1910 IPM - 16 APT -- 0.002 WOC -- 0.500 DOC -- 0.750
  • Tips film: Grooving - trochoidal turning By using the trochoidal technique, you can avoid chip jamming, vibration tendencies and residual stress thereby achieving higher process security.
  • Trochoidal milling/peel milling.With Iscar 12mm endmill Milling 25.4mm wide slot in ss2541 steel. Using Iscar 12mm endmill.Efs-e44 12-26c12cf83 ic900. 0.5mm each step 24mm cutting dept. Vc112m/min Fz0.31.
  • Trochoidal Machining Trochoidal machining with Tool-Flo ball nose end mill. Tool-Flo's patented Rigid Lock indexable ball nose end mill system ensures a secure fit of the insert with absolutely no movement. This allows for excellent indexabililty which improves productivity and quality.
  • Trochoidal (Peel) Milling With CamBam Trying out a new method of milling. So far it's working very well allowing far greater depths of cut which extends tool life and speeds up material removal.
  • CNC trochoidal milling-machining CNC - 2 to 5 axis milling machining from WorkNC, Sescoi CAD/CAM software. Trochoidal milling-machining. www.workncg3.com
