Inter-Drain 2028HRT Hydraulic Rock Trencher / Blackley (NZ) Blackley Construction Ltd from New Zealand is working with an Inter-Drain 2028HRT Rock Trencher machine. The Blackley Group consists of four separate Companies established in March 2000; however, Graeme Blackley started contracting already in the 1960.The machine has heavy duty chain specially developed to cut through stone. More info: www.inter- www.blackley.co.nz

sock trenching sock trenching for pond and storm sewer dewatering for Allstate Paving at Semoran Commerce Center.

trencher Simex/Cat trencher being used to box out pavement repairs

Inter-Drain 2028HT Dewatering Trencher / Raaijmakers (NL) Raaijmakers en Zn. From Volkel (NL) This company, located in Brabant (South of the Netherlands) is an institution in dewatering an Raaijmakers en Zn. From Volkel (NL) This company, located in Brabant (South of the Netherlands) is an institution in dewatering and has an experience of more then 40 years. Dewatering equipment is used to lower the groundwater table temporarily on a controlled depth. The Trencher installs first an unperforated pipe followed by a synthetic or organic wrapped perforated pipe. The drain length is determined by the drain diameter, soil-conditions and the water table. In general drain lengths of 50 and depths of 3 to 6 meters are common. After installation of the drainpipe a pump is connected to the drain and water can be pumped out. When the water table has been lowered the intended construction can start. As soon as the construction is finished the pumps can be stopped and the water table will rise again. More info: www.inter- www.inter-

Great Dorset Steam Fair 2008 Vintage trencher Great Dorset Steam Fair 2008 40th Anniversary of the biggest festival of this kind in the world . Working demonstration of old vintage trencher,this is a Parsons ladder ditcher from Newton Iowa USA, made under licence by John Allen and sons from Oxford UK A trencher pioneer. George W. Parsons Digital Camera used Panasonic DMC-TZ3 By: Landberg, Lynn George W. Parsons was one of the pioneers in manufacturing trenching machines. His first and smallest trencher was built in 1905, after which his trencher grew larger through the years. The biggest trencher, the 355, is capable of digging a 25-ft trench and was designed for pipe trenching. His company was sold several times, ending up with Seaman-Maxon. The last trencher under the Parsons name was manufactured in 1984. George Parsons began building trenchers in 1905. Although his company was sold several times, his name endures One of the pioneers in the manufacturing of trenching equipment was George W. Parsons, who began building trenchers in 1905 and soon was offering some of the smallest and largest trenchers around. Parsons' first trencher was a ladder trencher, or ditcher, so called because buckets were attached to a continuous chain, giving it the appearance of a ladder. The ladder assembly was lowered into the ditch, the chain turned, the buckets filled and the material was carried topside and discharged onto a side conveyor for dumping alongside the trench or into a truck. The counterpart of the ladder ditcher was the ...

1918 Buckeye Traction Ditcher Trenching Huge old Buckeye ditching machine is digging again after over half a century that left trees growing through it. 10' wide, over 32' long and weighing about 15 tons and more feet of chain than I don't know what! Four cylinder Climax TU gasoline engine provides the power.

Ditch Witch Trencher Safety Tips for safely and efficiently operating Ditch Witch riding or pedestrian trenchers.

Excavations in Construction/Trenching

Alpine Magnum Portable Trencher The Alpine Magnum portable trencher at is a low cost solution for sprinkler systems, electronic dog fences, cable trenches, french drains, irrigation trenches, waterfall pools, air conditioning and other trenching projects. Visit us at .

Trenching Machine Kennards Hire When you need a trench in a hurry grab a Kennards hire Red Roo or Dingo trencher. Contact Blair Edwards at Kennards Narre Warren, open 7 days 7am-5pm 03 9704-0444

Fordson Major trencher fitted with Rotopads. 1954 Fordson Major at Banbury Steam Fair at Bloxham in Oxfordshire UK on Sunday 28thJune 2010 ,the first tractor in the demonstration ring on Sunday afternoon. Not many people saw it because they were watching England in South Africa get knocked out of the football by Germany on the TV in the beer tent . I took this vid at the end of the show when the owner was loading it up onto his flatbed truck . The rear wheels were called Rotopad. Converted by Rotary Hoes Ltd., later called Howard Rotopad tracks. They are a type of track unit to achieve a Low Ground Pressure for working on soft surfaces. They were designed to replace the wheels on a tractor .The machine was used for cutting trenches in which originally were laid clay pipes for land drainage. These machines were developed over the years, certainly until the late 60s at which time they would be laying continuous plastic pipe, which of course is still used in land drainage today. This machine is a drainage trencher used for digging a trench and then manually pulling the pipes into a chute on the trencher which then laid the pipes as it moved slowly along putting clay pipes into wet land. After the pipes had been laid a tractor with a trailer having a side blade came along pushing the soil back into the trench. The machine in question is a Standard Fordson tractor with tracks that walked the machine along subsequently giving it better traction with less pressure on the ground than a wheeled type . They may look ...

CTC Marine: RT-1 Rock Trencher The RT-1 Rock Trencher is the worlds largest tracked underwater vehicle in the world. With 2.35MW of effective trenching power it is designed specifically for the burial of pipelines/trunklines in hard soil regions. The innovative, unique triple chain cutter configuration defines a wide, sloping V shaped trench allowing the stabilisation and protection of large diameter pipeline for trunkline burial. This methodology delivers improved economic and environmental benefits in comparison to other protection methodologies. RT-1s advanced designed pipe lifting technology allows the lift of heavy flooded pipelines. The unique cutting system is adaptable to allow burial of flexible products such as umbilicals and flowlines in a variety of soils. CTC operate some of the worlds largest, most technically advanced marine trenching vehicles and vessels enabling us to complete workscopes ranging from trenching, to a more comprehensive subsea protection service for the international offshore construction industry.

Good Old Ditch Witch Trencher

trenching a palm medjool date palm being trenched and pulled

Toro's Dingo Trencher Toro's Dingo Trencher, Digs 2' deep and 4" wide. Use for installing irrigation tubing.

Drainage Gutter Downspouts - Trenching For Yard Drainage Installation in Jacksonville, FL. Gutter downspout drainage installation. Visit for Trenching Services in Jacksonville FL. This is how we trench for yard drainage or installing drainage systems. Trenching comes in handy for installing gutter downspout drainage systems! If your having poor downspout dr

- Spring 2005 - Trenching in Tile Digging a trench to put tile in the ground for drainage

ramrod trencher After 5 minutes of training this operator was trenching!

Bobcat T190 trenching Trencher will dig 4 feet deep by 8 inches wide

MICRO-TRENCHING GROUT PUMP EQUIPMENT MICRO-TRENCHING GROUTER Patent Pending Delivering a revolutionary new technology solution that is swiftly changing the way fiber optic networks are deployed today requires new innovation in many areas including installation of the product, and the equipment used to complete the job properly. Remote control grouting to seal the trench. The MTGK-20 TRENCH GROUTER can seal 20 feet of duct per minute, or more, without any overflow, and no mess to clean up. The GROUT KING™ with the FW-1 Flow Wand can install the fiber optic cable air and water tight to reduce the moisture and debris from finding its way into cables, virtually eliminating expensive repairs. Any of our Grout Pumps can be outfitted with the remote control unit to make it the perfect grouting equipment for micro trenching applications.

Inter-Drain 1515HT Drainage Trencher / Japan Inter-Drain drainage trencher model 1515HT draining fields in Japan. This Inter-Drain 1515HT hydraulic chain trencher is the smallest drainage / utility machine in the Inter-drain trencher family. It weights only 8.4 tons and with a length of 7.5 and width of 2 meters it can be conveniently transported to the work-place. Regardless of relatively small size of the machine it can install pipe nearly to the same depth as its bigger "brothers". Digging depth of 1.8m and width from 0.13m to 0.5m are attainable. Volvo diesel engine provides up to 160 hp. This type of machines is used for installing drainage systems on all kinds of fields such as soccer, football, tracks, golf courses, orchards etc. More info: www.inter- www.inter-

Trenching with the Yanmar Digging irrigation pipe ditch with the yanmar

Micro-trenching at Google A video of micro-trench race filmed on Google campus April 16, 2010: a fun day focused on latest trenching technologies, innovation, and knowledge sharing. Thanks to all who participated!

Bobcat MT55 Trencher Bobcat MT55 using a trencher attachment to cut French drains. We used 2 inch big-O in the trench with clean stone and ran it into a catch basin.

Excavations & Trenching This procedure provides guidance to Contractors for the protection of personnel working in and around excavations and trenching and clarifies the following topics. Terminology, General Requirements, Access Set Back, Equipment, Dust, Confined Space, Training, Filing Excavation, Protective System, (Protection of Employees) Soil Classification, Sloping/Benching, Support System, Shield System, Other Protection Systems, Permit System, Supporting Documentation, Daily Trenching Log, Excavation Checklist

Trenchnedge Trencher 13hp Irrigation & Deep Drain Tile Model This trencher was specifically designed for the irrigation installation and maintenance industry. It is the only trencher that discharges the trenched material direct onto tarps on either side of the machine for easy clean-up. The trencher can make multiple trenches side-by-side to run multiple main lines in the same trench. Not only will it trench for conventional irrigation systems, but our new "Blade-in-a Blade" technology allows you to trench for subsurface drip irrigation, low voltage lighting and dog fencing using the same blade. Our patented floating cutting blade is designed to cut up and over underground obstructions like rocks and large tree roots, which saves on high trencher blade maintenance costs. The trenching teeth cut up to 2.5" wide on each pass. Our subsurface drip blade can cut a 1" wide trench. The depth is adjustable from 0" to 12" deep depending on the model chosen. The specially designed trencher teeth are made of replaceable carbide bits that are mounted on steel holders or in rocky areas you can specify "Shark Teeth". In addition this trencher can excavate for brick edging, landscape retaining walls, drain tile, silt fence, low voltage lighting cable, water lines and root pruning.

Single Ladies by McCarthy Trenching McCarthy Trenching spent most of 2007 touring, with an extended opening slot on the Bright Eyes Cassadaga tour, a date here and there warming the stage with the likes of M. Ward, Victoria Williams, Jason Isbell, Mark Olson and even radio hit Peter, Bjorn & John. Then we came home for a bad Nebraska winter, spending most of our time shoveling snow and recording songs. McCarthy Trenching prefers to record at home, since there is so much snow-shoveling to do during the winter. All of the songs were recorded on 8-track tape machines, mostly in the living room, because thats where the piano is.

McCarthy Trenching - The Most Attractive Disguise Directed by Mark Maziarz at Notes On McCarthy Trenchings Calamity Drenching: A. McCarthy Trenching just bought a packet of cigarettes and a bottle of Old Overholt and came home to write this intro for the blurb on his new record (here we are). After having played a benefit concert for a little boy who was badly burned when he tipped a vegetable steamer over onto himself. After having made a promise to an old friend that no songs about horse racing would be played at the concert, on account of the cruelties of the sport, a promise which was broken. McCarthy Trenchings latest songs tend to be centered around rejections: romantic ones, religious ones, rejections of high holidays and of higher education, the rejection that happens when a driver hits eject on her tape player and throws the cassette out the window. McCarthy Trenching is probably a couple deep right now. B. McCarthy Trenching spent most of 2007 touring, with an extended opening slot on the Bright Eyes Cassadaga tour, a date here and there warming the stage with the likes of M. Ward, Victoria Williams, Jason Isbell, Mark Olson and even radio hit Peter, Bjorn & John. Then we came home for a bad Nebraska winter, spending most of our time shoveling snow and recording songs. The result is Calamity Drenching, a collection of songs about horse racing, the romance of cassette tapes (and losing that particular romance), piano practice, religious doubt, inclement weather, and Bar-BQ. And there is ...

BARRETO 712MT TRENCHER Designed with the do-it-yourselfer in mind, this trencher will make short work of sprinkler systems, dog fences and other shallow applications.

Inter-Drain 3035T Trenching Machine / India Inter-Drain drainage trencher model 3035T laying collector pipe in India. Update coming soon. More info: www.inter- www.inter-

Ditch Witch HT220 Heavy-Duty Trencher Part 1 Demonstration of powerful Ditch Witch HT220 trencher, a rock-digging workhorse capable of trenching up to eight feet (2.4 m) deep and up to 24 inches (610 mm) wide in the most extreme jobsite conditions.

Trenching & Excavation Safety The NAHB Construction Safety & Health Committee is dedicated to helping builders operate safe jobsites, comply with OSHA regulations, and lower workers' compensation costs through injury prevention. This excerpt from NAHB Construction Safety & Health's Trenching & Excavation Safety Video highlights the most common hazards associated with residential trenching and excavation. For Information on the complete video please contact Rob Matuga, AVP NAHB Labor Safety & Health, at rmatuga@. Other NAHB Safety & Health video offering, such as Job Site Safety, Fall Protection, and Scaffold Safety, are available at /safety. All NAHB Safety & Health video productions are available in both Spanish and English.

Stratti Rocksaw Trenching Hard Rock...Hitachi EX1200 www.Rock-

Excavation and Trenching Trenches and excavations are common at many construction sites and are considered one of the most dangerous construction operations. OSHA requires that workers in trenches and excavations be protected. Most fatalities and injuries could be avoided with proper knowledge, utilization of OSHA safety standards and an effective health and safety program. We can provide materials to aid in this training. For more information on these materials please contact National Safety Compliance at 1.877.922.7233 or visit us online at www.osha-safety-.

Ditch Witch HT220 Heavy-Duty Trencher Part 2 Demonstration of powerful Ditch Witch HT220 trencher, a rock-digging workhorse capable of trenching up to eight feet (2.4 m) deep and up to 24 inches (610 mm) wide in the most extreme jobsite conditions.

Mini HDT - Hydraulic Disc Trencher The TrenchIT HDT is the latest in mini skid steer trenching. The Trench It HDT is a hydraulic run disc-type trencher, designed for the installation of sprinkler systems, underground electric fences and general cable laying. Also perfect for the orchard irrigation jobs.

BRADER LAND DRAINAGE MASTENBROEK TRENCHING MACHINE 1 Mastenbroek are World leaders in drainage technology and our 30/20 Trencher represents the industry standard for agricultural drainage. Using the latest laser technology, the machine checks for precise depth 60 times every minute and ensures consistent results every time. As the trench is cut the flexible drainage pipe is simultaneously laid, whilst the gravel hopper follows close behind and lays the porous fill. The result is a fully-automated process which produces consistently high quality, whilst cutting down on labour time and cost. Due to it's wide tracks the Mastenbroek Trencher causes very low ground pressure which results in minimal disturbance to the surface of the field. This factor makes the machine very flexible in its application and is ideally suited to agricultural use as well as sports and recreation grounds where damage limitation is paramount. As the video shows, the trenching process is quickly completed with a back-fill by tractor and the site is left in the same good condition as when we arrived. If you would like more information about any of our drainage services, please contact us on 01507 603722 or email mick@.

CTC Marine UT-1 Jet Trencher Animation The UT-1 is the worlds most powerful jetting ROV with 2.1MW of total power. It is also fitted with sophisticated drive motors, which allow precise control of pressure and flow, giving a high degree of control and flexibility when undertaking subsea workscopes in varied environmental conditions. The UT-1 can provide rapid installation of flexible flowlines and submarine cables using its bell mouth and cable capture tool, whilst its upgraded swords allow jetting performance exceeding any other jet trencher currently in the market place. With an extensive track record, the UT-1 is configurable for a wide range of applications including trenching of pipelines through to the installation of submarine cables in varying seabed conditions. The ROV is suited to the offshore Oil and Gas, Life of Field Seismic, Telecommunications, E-field, Power and Renewables markets. The UT-1 is permanently installed on the multi-role subsea construction vessel, Volantis, with a state-of-the-art heave compensated launch and recovery system, which includes a submersible latch beam, cursor and high speed constant tension winches.

vintage trenching machine they don't make them like this any more! this is one of my howard rotary hoe trencher based on fordson major. it has a perkins 4 cylinder conversion the log book tells me it was manufactered in1961! this video was taken august 2009 and it took just over an hour to trench 100 metres!

Micro Trenching - TeraSpan This video provides an overview of how micro trenching is done and what a completed network looks like. TeraSpan has branded this as Vertical Inlaid Fiber or VIF. The conduit is applied as two halves over top of the fiber. This provided many advantages in installation and in maintenance. This type of fiber network can be used for fiber to the home, private fiber networks, connecting wireless networks, long haul networks along roadways etc. TeraSpan has pioneered this deployment method and now provides its products and expertise around the globe.

Inter-Drain 1515HT Drainage Trencher / Jimmink-Kolhorn (NL) Jimmink-Kolhorn from Bassingerhorn. Their Inter-Drain 1515HT Drainage/Utility trencher is working in Noord Holland. Here you can see the installation of a sub-surface drainage system on a new soccer/football field. This Inter-Drain 1515HT hydraulic chain trencher is the smallest drainage / utility machine in the Inter-drain trencher family. It weights only 8.4 tons and with a length of 7.5 and width of 2 meters it can be conveniently transported to the work-place. Regardless of relatively small size of the machine it can install pipe nearly to the same depth as its bigger "brothers". Digging depth of 1.8m and width from 0.13m to 0.5m are attainable. Volvo diesel engine provides up to 160 hp. This type of machines is used for installing drainage systems on all kinds of fields such as soccer, football, tracks, golf courses, orchards etc. More info: www.inter- www.inter-

Vacuum Excavation - Slit trenching ADP Group Ltd demonstrate installing a root barrier to prevent tree roots causing unwanted damage to a property, using revolutionary Hydro Vacuum Excavation techniques. For more information please visit or contact Tom Page 07817 419 954 - tpage@
