nondestructive

Examples

Videos

  • 56 ft. Tubing for Ultrasonic Nondestructive Testing 56 ft. tubing delivery for immersion ultrasonic (UT) nondestructive testing at Laboratory Testing Inc.
  • Non Destructive Testing (NDT) Ford 460 Cylinder Head John Edwards @ Costa Mesa R&D Automotive Machine demonstrates non destructive testing (NDT) magnetic particle inspection (Magnaflux) on a 460 Ford cylinder head to determine if the head is cracked. www.engine- (949) 631-6376
  • Non-Destructive Workflow Learn the basics behind successful non-destructive photo editing with Alien Skin products.
  • ANULAB Non Destructive Testing of Concrete by Rebound Hammer Rebound hammer test is done to find out the compressive strength of concrete by using rebound hammer as per IS: 13311 (Part 2) - 1992. The underlying principle of the rebound hammer test is The rebound of an elastic mass depends on the hardness of the surface against which its mass strikes. When the plunger of the rebound hammer is pressed against the surface of the concrete, the pring-controlled mass rebounds and the extent of such a rebound depends upon the surface hardness of the concrete. The surface hardness and therefore the rebound is taken to be related to the compressive strength of the concrete. The rebound value is read from a graduated scale and is designated as the rebound number or rebound index. The compressive strength can be read directly from the graph provided on the body of the hammer. Procedure to determine strength of hardened concrete by rebound hammer. i) Before commencement of a test, the rebound hammer should be tested against the test anvil, to get reliable results, for which the manufacturer of the rebound hammer indicates the range of readings on the anvil suitable for different types of rebound hammer. ii) Apply light pressure on the plunger - it will release it from the locked position and allow it to extend to the ready position for the test. iii) Press the plunger against the surface of the concrete, keeping the instrument perpendicular to the test surface. Apply a gradual increase in pressure until the hammer impacts. (Do not touch the ...
  • Arrow Gear NonDestructive Testing Arrow Gear performs nondestructive tests including Surface Temper Inspection and Magnetic Particle Inspection
  • Daryle Higginbotham, President Marietta Nondestructive Testing, Inc. - IMPACT November 10, 2010 - IMPACT Presents Daryle Higginbotham, President Marietta Nondestructive Testing, Inc. Daryle Higginbotham founded Higginbotham & Associates, Inc. in 1988. The firm's focus was custom machine design and fabrication with a full range of manual and machining services for steel, tungsten, aluminum and plastics. In 2000, Mr. Higginbotham established Marietta X-Ray, Inc., to design, fabricate, install and service integrated x-ray inspection systems for the Departments of Energy and Defense, and the aerospace, automotive and manufacturing industries. Marietta Nondestructive Testing, Inc. was created in 2008 when the company expanded its capabilities to include systems utilizing ultrasonic and eddy current testing technologies. Mr. Higginbotham is a 1989 graduate of Southern Polytechnic State University (formerly known as Southern College of Technology) with a Bachelor of Science Degree in Mechanical Engineering Technology. In 1982, he received his Machinist and Toolmaker Certificate from Lanier Vocational School in Gainesville, Georgia. Mr. Higginbotham currently serves as an advisor for the Mechanical Engineering Department at Southern Polytechnic State University. Other civic involvement includes the Cobb Chamber of Commerce, the Rotary Club of Marietta Metro, and the SPSU Foundation Board. Mr. Higginbotham is married to the former Rebecca Fritchley, a graduate of Georgia Tech with a degree in Architecture, and they are the parents of Bryan, 21, and Katie, 19.
  • Nondestructive Testing Test material prior to machining or fabricating, or test parts before they are installed into service. Laboratory Testing Inc.—LTI— provides nondestructive testing—NDT for detecting surface and sub-surface defects on parts and materials. No matter what shape or size material, LTI can evaluate its quality and integrity, using methods such as ultrasonic testing, liquid penetrant inspection, magnetic particle inspection, X-ray inspection, hydrostatic pressure testing and visual inspection.
  • PhotoTechEDU Day 18: Non-destructive, Selective, Editing... Google Tech Talks May 16, 2007 ABSTRACT For photo editing tools there is a lot of buzz about non-destructive or parametric editing. While this is quite standard for todays RAW converters it is not sufficient for a more refined imaging workflow. The talk will demonstrate the need for a Non-destructive, Selective, Non-linear and Non-modal editing workflow. # useful properties of light and image formation # theory and techniques of photographic optics and image capture # theory of colorimetry and techniques of color reproduction # where and how photography is being used in Google products and projects # what tools exist inside Google for photographic image storage, processing, etc. # and lots...
  • Non Destructive Examination This promotional spot highlights non destructive program at Central Piedmont Community College.
  • Sharpening and non destructive dodging and burning Taken in very harsh lighting conditions we first look at selectively sharpening the image before using a non destructive way of dodging and burning. This will allow us to bring out the detail from shadows areas and darken down highlights and keeping the whole process fully adjustable. To visit Steve Jones web site click HERE
  • Using Non-destructive Retargeting Level: Intermediate Recorded in: Maya 2011 Description: This movie shows how to use retargeting between separate rigs using the HumanIK solver.
  • Non-Invasive, Non-Destructive and Remote Identification of Depleted Water Trap Seals - Part 1 "The Non-Invasive, Non-Destructive and Remote Identification of Depleted Appliance Water Trap Seals" - Professor John Swaffield, Heriot Watt University Part 1 of 5 The 2004 IAPMO Symposium highlighted the role of dry traps in the 2003 Amoy Gardens SARS epidemic, a plumbing failure identified by WHO as implicated in 321 cases resulting in 42 deaths. Following the symposium the Drainage Research Group at HWU investigated an application of transient theory that could identify dry traps due to the difference in wave reflection between a full and dry trap. Mention at the 2005 WPC Auckland Conference was followed by a $0.5M EPSRC UK Research Council 3 year award to HWU. A Steering Committee from organisations concerned with drainage design and public health, including IAPMO, BuroHappold, CIBSE, SNIPEF, Studor and RBS, also contributed advice, further financial support and provided test sites. This highly successful research collaboration led to an operational non-invasive, non-destructive, remote testing methodology that propagates a 10 Hz, 30mm water gauge pressure transient into a building drainage network, via an exciter installed below the system roof termination. Comparison of a defect free system transient response to that including a defective trap, identifies the trap location as the traces diverge at the time taken by the transient to travel, at the acoustic velocity in air, 343 m/s, from the monitoring station to the defect and return, implying a test duration ...
  • Presentation Thai Nondestructive Testing PCL. (THAILAND) Thai Nondestructive Testing PCL. TNDT is a technical service company which was established in 1982 by a group of academics, experts, specialist engineers and technicians specializing in the various technical fields in response to the growing demands for NDT related services, especially for Engineering Inspection and Nondestructive Testing of pressure vessels, heat exchangers, boilers, piping and structure in the fields of oil refinery, power plant, petrochemical plant, ship building, offshore, bridge and building construction, and other various heavy industries.
  • TEDxDUBLIN - Jonathan Siegel -- Non-destructive Testing Jonathan Siegel is the founder of the consultancy ELC Technologies. As an entrepreneur, he has had a founding role in three Ruby on Rails product businesses: , and . He holds degrees in physics and computer science from the University of California, Santa Barbara. AboutTEDx, x = independently organized event In the spirit of ideas worth spreading, TEDx is a program of local, self-organized events that bring people together to share a TED-like experience. At a TEDx event, TEDTalks video and live speakers combine to spark deep discussion and connection in a small group. These local, self-organized events are branded TEDx, where x = independently organized TED event. The TED Conference provides general guidance for the TEDx program, but individual TEDx events are self-organized. (Subject to certain rules and regulations.)
  • Non Destructive Editing Tutorial A tutorial on how to edit photos using an alternative dodge and burn technique using adjustment layers.
  • Inside Jobs Non Destructive Examination Nondestructive Examination
  • ANULAB Non Destructive Testing NDT by Rebound Hammer & Ultrasonic Pulse Velocity at Railway Culvert This test is done to assess the quality of concrete by ultrasonic pulse velocity method as per IS: 13311 (Part 1) 1992. The underlying principle of this test is - The method consists of measuring the time of travel of an ultrasonic pulse passing through the concrete being tested. Comparatively higher velocity is obtained when concrete quality is good in terms of density, uniformity, homogeneity etc. Procedure to determine strength of hardened concrete by Ultrasonic Pulse Velocity. i) Preparing for use: Before switching on the V meter, the transducers should be connected to the sockets marked TRAN and REC. The V meter may be operated with either: a) the internal battery, b) an external battery or c) the AC line. ii) Set reference: A reference bar is provided to check the instrument zero. The pulse time for the bar is engraved on it. Apply a smear of grease to the transducer faces before placing it on the opposite ends of the bar. Adjust the SET REF control until the reference bar transit time is obtained on the instrument read-out. iii) Range selection: For maximum accuracy, it is recommended that the 0.1 microsecond range be selected for path length upto 400mm. iv) Pulse velocity: Having determined the most suitable test points on the material to be tested, make careful measurement of the path length L. Apply couplant to the surfaces of the transducers and press it hard onto the surface of the material. Do not move the transducers while a reading is being taken, as this ...
  • Ultrasound Non-Destructive Testing NDT of Composite Carbon Material This video demonstrates the verification of a repaired floor piece using Ultrasound NDT. For more information, see our website: www.scsolutions-
  • nondestructive.avi
  • NIWeek 2010 Ultrasonic Imaging and Non-Destructive Test with NI FlexRIO In this video, we show how NI FlexRIO can be used to create non-destructive test (NDT) and ultrasound imaging systems for phased array and other high channel count applications. NI FlexRIO combines modular I/O with a user programmable FPGA and allows the user to create customizable and scalable systems. In the demo, we have a 32 channel pulser module and 32 receive channels, as well. Specifically, we are using the NI 5752 32-channel digitizer adapter module, which is capable of sampling on all channels at 50 MS/s with 12-bit resolution. The module uses the TI AFE5801 and is optimized for nondestructive test (NDT) and ultrasound applications with built-in ***og-to-digital converter (ADC) features such as selectable antialias filters and programmable time-variable gain control. Once data is acquired, you can implement your own high-speed control and inline processing algorithms in the FPGA, including fast Fourier transforms (FFTs), filtering, peak detection, and gating. In addition, you can synchronize multiple modules for higher-channel-count systems. In the demo, we show the raw acquired data, 2D B-scan image after the beamforming processing is implemented, and even real-time 3D imaging.
  • Nondestructive Mask Effects - Photoshop CS5 Tutorial
  • Non-Destructive Chop (MPC1000 & MPC2500 JJ OS) Please refer to the following link for a non-destructive chop. www7a.biglobe.ne.jp JJ OS is downloadable from the following site. MPC1000 JJ OS www7a.biglobe.ne.jp MPC2500 JJ OS www7a.biglobe.ne.jp
  • Non Destructive Testing (NDT) BY Eddy Current Marposs offers the following solutions for non destructive testing based on eddy current technology: Material integrity test. Material properties test. HRC test. Thread inspection.
  • Kodak Zi8: 2/2 Non-destructive removable wide angle lens mod Part 2 of 2: I used Loctite brand epoxy putty to make a removable frame to hold a wide angle lens on a Kodak Zi8 video camera. I used epoxy, because it is not affected by heat as much as the moldable plastic you can buy online. I did not glue anything directly to the camera, nor did I have to take it apart to add a magnetic ring like a popular lens mod from china, so no warranty was voided and no damage occured to the camera.
  • Nondestructive Testing (NDT) of large structural I-Beams using Ultrasonic EMAT The temate® IB is an automated, integrated Nondestructive testing (NDT) system which uses Ultrasonic EMAT technology. EMAT is a type of ultrasonic testing in which the sound is Induced into the part by electromagnetic interaction. Since sound is created in the part being inspected, no liquid couplant is used, thus EMAT is an excellent choice for automated installations where couplant maintenance is problematic, for inspecting materials at extreme temperatures (very hot or very cold) where liquid will freeze or boil, and for exploiting the benefits of ultrasonic guided waves, which are quite effectively produced with an EMAT as compared to piezoelectric ultrasonic inspection.
  • Non-Invasive, Non-Destructive and Remote Identification of Depleted Water Trap Seals - Part 4 "The Non-Invasive, Non-Destructive and Remote Identification of Depleted Appliance Water Trap Seals" - Professor John Swaffield, Heriot Watt University Part 4 of 5 The 2004 IAPMO Symposium highlighted the role of dry traps in the 2003 Amoy Gardens SARS epidemic, a plumbing failure identified by WHO as implicated in 321 cases resulting in 42 deaths. Following the symposium the Drainage Research Group at HWU investigated an application of transient theory that could identify dry traps due to the difference in wave reflection between a full and dry trap. Mention at the 2005 WPC Auckland Conference was followed by a $0.5M EPSRC UK Research Council 3 year award to HWU. A Steering Committee from organisations concerned with drainage design and public health, including IAPMO, BuroHappold, CIBSE, SNIPEF, Studor and RBS, also contributed advice, further financial support and provided test sites. This highly successful research collaboration led to an operational non-invasive, non-destructive, remote testing methodology that propagates a 10 Hz, 30mm water gauge pressure transient into a building drainage network, via an exciter installed below the system roof termination. Comparison of a defect free system transient response to that including a defective trap, identifies the trap location as the traces diverge at the time taken by the transient to travel, at the acoustic velocity in air, 343 m/s, from the monitoring station to the defect and return, implying a test duration ...
  • Occupational Video - Non-Destructive Testing (NDT) Technician Non-Destructive Testing Technicians use special inspection methods that give information about the condition of materials and components without destroying them.
  • Nondestructive Testing A group of researchers at Missouri University of Science and Technology in Rolla has developed a handheld camera that uses microwave signals to non-destructively peek inside materials and structures in real time. Video by Tom Shipley, [email protected]
  • Non Destructive Dodging & Burning in Photoshop Non Destructive Dodging & Burning in Photoshop using layer blending modes
  • Kodak Zi8: 1/2 Non-destructive removable wide angle lens mod Part 1 of 2: I used Loctite epoxy putty to make a removable frame to hold a wide angle lens on a Kodak Zi8 video camera. I used epoxy, because it is not affected by heat as much as the moldable plastic you can buy online. I did not glue anything directly to the camera, nor did I have to take it apart to add a magnetic ring like a popular lens mod from china, so no warranty was voided and no damage occured to the camera.
  • SAMA Italia Non Destructive Testing Equipment (NDT) Product Range 2011 SAMA Italia Srl presents her Non Destructive Testing product range suitable for industrial and environmental control distribute through the SAMA Tools brand. SAMA Italia Srl operates since more than 30 years alongside the most important firms in the base production industry in many approaches, from offering consulting services in the CNC CAD CAM field to design, manufacture and distribution of measuring and control instruments through her own brands. In this video we are proud to show you a part of our instruments, while you can take a look at the whole product range visiting our website www.samatools.it, where you can download our catalogue, be updated on our latest offers and find the best equipment like: Test stands pH meters Luxmeters Tachometers Stroboscopes Data loggers Vibration meter Anemometers Force gauges Sound level meters Holiday detectors Gas detectors Geiger counters Color difference meters Gloss meters Surface roughness testers Shore hardness testers Thermoigrometers Cross hatch adhesion tester Gran moisture meters Thermal cameras Schmidtt type hammers Flaw detectors Coating hardness testers Infrared thermometers Materials moisture meters Ultrasonic hardness testers Coating thickness gauges Sound level meter calibrator Leeb hardness testers Paint film bend testers Bucholz indentation hardness testers K type temperature meters Optical and digital refractometers Ultrasonic thickness gauges And every related standard samples or calibration standards We are ...
  • Non-Destructive Live Retargeting — Maya 2011 New Features More quickly and easily reuse, correct, and enhance motion-capture and certain other animation data with a new non-destructive retargeting workflow which uses the Autodesk® HumanIK® (HIK) libraries. Transfer animation from one character to another and adjust retargeting parameters live to see and edit results without the need to re-bake.
  • Non-Destructive, Live, Worry-free Photo Editing for your Mac Video clip show you how Ohanaware Funtastic Photos works its magic, an easy to use Mac photo editor. Free trial at Bunch of useful freeware can be found
  • Photoshop: Non-Destructive Editing Facebook Page Twitter: One of my favorite things in photo editing is being able to edit non-destructively!
  • Non-Invasive, Non-Destructive and Remote Identification of Depleted Water Trap Seals - Part 2 "The Non-Invasive, Non-Destructive and Remote Identification of Depleted Appliance Water Trap Seals" - Professor John Swaffield, Heriot Watt University Part 2 of 5 The 2004 IAPMO Symposium highlighted the role of dry traps in the 2003 Amoy Gardens SARS epidemic, a plumbing failure identified by WHO as implicated in 321 cases resulting in 42 deaths. Following the symposium the Drainage Research Group at HWU investigated an application of transient theory that could identify dry traps due to the difference in wave reflection between a full and dry trap. Mention at the 2005 WPC Auckland Conference was followed by a $0.5M EPSRC UK Research Council 3 year award to HWU. A Steering Committee from organisations concerned with drainage design and public health, including IAPMO, BuroHappold, CIBSE, SNIPEF, Studor and RBS, also contributed advice, further financial support and provided test sites. This highly successful research collaboration led to an operational non-invasive, non-destructive, remote testing methodology that propagates a 10 Hz, 30mm water gauge pressure transient into a building drainage network, via an exciter installed below the system roof termination. Comparison of a defect free system transient response to that including a defective trap, identifies the trap location as the traces diverge at the time taken by the transient to travel, at the acoustic velocity in air, 343 m/s, from the monitoring station to the defect and return, implying a test duration ...
  • Non-destructive MP3 editing (retain the original sound quality) Many people don't understand that every time you save MP3 files, you are slightly degrading the original sound quality, which was lossy to begin with. MP3 works on the principle of perceptual coding, whereby sounds not typically audible to the human ear are removed or allocated fewer bits, in addition to other types of data compression. The higher the MP3 bitrate, the less data is removed, and the audio remains closer to its original purity. Different MP3 encoders also vary in quality and implementation. If you want to be *** than the average fool, don't edit your MP3 files in a standard sound editor unless you need to make major structural changes that can't be done with a lossless MP3 editor. mp3DirectCut is a very good freeware program that lets you cut, paste and fade MP3 clips without affecting the original sound quality. It is highly recommended for people with above average intelligence who appreciate good sound but understand the tradeoffs of the MP3 format. This author recommends using the LAME VBR "standard" MP3 setting for the optimal balance of file-size and sound quality.
  • Fabrication: Non destructive Testing Fabrication: Non destructive Testing: training video from the Corus BCSA training pack
  • Non Destructive Entry Now you know how a court gains entry to a property after being issued with a magistrates warrant.
  • NDT Services - Non-Destructive Testing Services Overview This modern and fast-paced video for East-Midlands based firm NDT Services Ltd is the perfect example of how video can act as a marketing, presentation and promotional tool for businesses in more technical industries. In only 7 minutes the audience is brought 'up to speed' on the services, standards and ethos of this exciting company. For more information go to
  • elevator rope non-destructive inspection Testing locale of TCK wire rope non-destructive defectoscope for elevator
  • BlisterScan: Non-destructive leak testing machine - pharmaceutical blister packs -Sepha BlisterScan: Sepha's non-destructive leak test machine for pharmaceutical blisterpacks. Methylene blue dye test alternative. Save money! Reduce waste! Sepha's BlisterScan identifies leaks as small as 7µ in individual blister pockets of pharmaceutical or medical blister packs. BENEFITS: Non-destructive test generates less waste and bigger product yield ◦The non-contact laser scanning method is clean and dry, unlike other destructive leak testing methods (eg Methylene Blue Dye Test), and does not destroy test product or packaging. ◦Tested product can be retrieved from faulty packs and repackaged. ◦Packs which pass the leak test can be put back onto the production line. Sepha's BlisterScan pinpoints micro holes and weak seals in: ◦Non-porous blister packs in materials such as PVC, PVDC, ALu/Alu, Aclar etc ◦Blisters containing solid dose products such as tablets, capsules or medical devices. ◦Multiple blisters from a full sealing index measuring up to 320mm Width x 150mm Length
  • Nondestructive testing of materials Nondestructive testing of materials with an eddy-current sensor. Discretization and contour plot of the surface currents. Visit for more information
