Jet Ski Big Bore Machining John's at it again with another machining project, this time he's machining a Yamaha 700 engine out of a Jet Ski. Watch as he machines the block for a big bore kit. www.Engine- (949) 631-6376
DVD Volume 2: CNC Guitar Machining visit This video is a preview of the guitar that is cut out in DVD Volume 2 Guitar Machining. Video 1: Guitar modeling in Aspire v2.5 Video 2: Guitar machining with a Shopbot CNC machine. This video series will take you from 3D guitar modeling all the way through final construction of a playable instrument. The videos are available for purchase at
Mastercam's High Speed Machining A compilation of CNC cutting using Mastercam's high speed machining toolpaths.
Electrical Discharge Machining with old Doorbell Parts Jeri shows a machine for spark machining with a doorbell solenoid. Example work piece is a stainless steel razor blade.
Mikini 1610L CNC machining center - Circular interpolating in 1045 carbon steel This video features the Mikini 1610L CNC machining center circular interpolating a 1.660" hole in 1045 carbon steel using a 3/8 carbide end mill. 35% Spindle load. This part is for a press fit application on precision ground rod stock, circular to better than 0.001" TIR, with the whole part slightly eccentric on the shaft. Compared to 1018, consider that 1045 has over double the carbon content of 1018 (0.45% vs 0.18%) and Machinability of 1045 is 19% compared to 1018's 35%. Aluminum soft jaw also machined on the 1610L. The 1610L CNC machine was designed to be owned, operated and maintained by engineers, business owners and R&D shops. You can purchase this machine for $11999. It runs on single phase power, is fully enclosed, and only takes 3'x5' of space. Perfect for your garage, small business, R&D lab or home shop.
Concept car CAD/CAM- CNC 5 axis machining concept car CNC 5 axis machining. Milling, roughing, semi-finishing, by WorkNC CAD/CAM software.
Trend CNC Machining Centres www.trend- Trend's range of computer controlled routing machines for a wide range of applications Fully guarded as standard for maximum safety. Visit our website for comprehensive information on the entire Trend range and details of your nearest stockist.
Welding Stainless Steel 303 Free Machining Stainless Welding Stainless Steel is pretty easy compared to welding free machining 303 stainless steel. Sulphur is the culprit. Tig welding Techniques for 303 free machining stainless steel involve a tight arc and extra filler metal.
Machining a Large Aerospace Part on a Makino MAG 5-axis Horizontal Machining Center This video is of a Makino MAG 5-axis horizontal machining center cutting a large aerospace structural part made of aluminum. For more on aerospace machining, view this free webinar on High Speed Machining in Large Airframe Applications bit.ly Video property of Makino.
High Speed Machining Toolpaths Changing American Manufacturing Looking for true high speed machining? Our revolutionary high speed machining toolpaths will turn any machine and any CAM system into a metal eating monster. Watch as we eat up 6061-T6 Aluminum at 350 IPM and a spindle rate of 10000 rpm. Dramatically reduce cycle times and increase your speeds and feeds to save costs, time and money. Watch what our toolpaths can do for high speed machining steel. Here we have 4140 steel at 10000 rpm and 1300 sfm which is 4 times the manufacturer's recommended settings. Watch as we go a half inch deep at 250 IPM. High speed machining of harder materials? How about 6AL4V Titanium? Here we machine titanium at 126 IPM with a 1 inch deep cut and a spindle speed of 3820, again 4 times the manufacturer's recommendations. Now you can enjoy true high speed machining, dramatically increase your speeds and feeds, slash your cycle times and actually increase your tool wear life by over 200%. Isn't it time you stepped up and enjoyed true high speed machining in your shop? Check out our 15 day trial offer, try it first and see how easy our universal high speed machining toolpaths can change your machine efficiencies.
Impeller machining on five axis StarragHeckert machiningcenter The efficiency of radial compressor wheels depends to a high degree on the precision of the production process. This is something to which we are well suited as a worldwide recognised specialist in the field of 5D milling technology, as high-precision machining of impellers has been one of the specialist areas of StarragHeckert for many years. With the STC 100 we have set another milestone.
Diamond 20CSB machining a pagoda No description.
Matsuura Maxia: W16 Engine Block Machined From Solid Billet Video of a Matsuura MAM72-42V 5 axis CNC machine cutting a W16 Engine Block from solid billet
Rollco - Ball Screw machining How to machine and mount a Rollco custom ball scew. We customize ball screws to suit your requirements - shortening, annealing and working the screws individually. actuator ball screw ball bearing screw ball screw ball screw actuators ball screw bearings ball screw company ball screw how...
CNC Basics E-Course 6 | CNC Machining | Learn CNC ... On Day 6 we learn about CNC Machining. This is where the rubber hits the road. Before this, we did virtually everything on the computer. Now we move into the real world. Machining is about removing material from a piece of stock until we finalize our parts. One thing we learn is that...
CNC Machining Demo Workpiece At AMB Fair 2008 Emuge UK Ltd. is part of the 1000 employee German parent company EMUGE-FRANKEN. The company manufactures an exhaustive line of taps, end mills, thread mills, thrillers, holders and attachments. Over 110000 top quality tools "Made in Germany" are sold through distributors worldwide. For more information about "Emuge UK Ltd", please use this link: www.emuge- Whynot also check out the website as is not just another online directory, it is a B2B site run by experienced tooling engineers for engineers and designed to be a true tooling guide crammed full with blue chip companies, high technical content and useful links
Mastercam Extreme Machining See Mastercam X2 in action with 5-axis machining choreography.
5 axis CNC Machining - Biedermeier armchair prototype 5axis CNC - Machining Biedermeier sofa and armchair prototype. Solid wood. Router made by AJ Grupp, Estonia. www.5-axis-
Matsuura Maxia: 5 Axis Unmanned Multi Pallet Machining Short clips showing the versatility & high end performance of Matsuura 5 Axis CNC Machine Tool Products. More info from
Matsuura Maxia: V8 Engine Block Machined From Solid V8 Engine Block Machined From Solid on a Matsuura 5 axis MAM72-63V CNC state of the art Machine Tool
impeller/Turbine CAD/CAM-CNC 5 axis machining Aerospace impeller/Turbine CNC 5 axis machining. Milling, roughing, finishing with WorkNC CAD/CAM software.
Vertical Machining Center HEIDENHAIN DVH-1200 Vertical Machining Center We thank you for your inquiry and we take pleasure in submitting our quotation as follows: Now standard with high speed rapids of 1425IPM on the (X) and (Y) axis, 791IPM on (Z) axis -- Roller Guideways -- and a 24 Tool ATC, the LITZ DVH 1200 is unique because it is the only 40 taper machine available that has both high cutting torque and 15000 min-1 spindle speed. Now one machine delivers the machining capabilities that before required two machines. This machining center has the highest metal removal rate of any machine in the 40 taper class. The Litz DVH-1200 incorporates pre loaded roller ways. The bed, column, saddle and other major components are all made of the highest quality Meehanite cast iron. The table is ground to better than a 16 micron finish. Fully supported travels on the (X) and (Y) axes eliminate any table overhang. This greatly increases accuracies over the entire table travel. Solid tapping (Rigid Tapping) is a standard feature. High-speed tapping can be accomplished without using a floating tap holder. Litz uses a ATC design to achieve a fast tool change time. The ATC magazine has a 24-tool capacity. The ATC is designed for reliable, yet maintenance free operation. The tool magazine is located up and away from the machining environment. This design keeps any contaminants (coolant, oil, and chips) away from the tool magazine. To control thermal distortion of the spindle, spindle oil is re-circulated through ...
GTV-27 Broaching Demo The GTV-27 gang-tool lathe turns a 1" brass stock using two operations. The first operation includes milling with C-axis synchronization, high-speed threading, and C-axis drilling. The second operation performs nibbling broaching with C-axis synchronization.
Machining the Model Stickney Engine with Lathe and Mill How I machined the casting I made. This is a large casting for my machines so some unusual set ups were used. You can see the casting being made in one of my other videos-Metal Casting at Home part 10
CNC machining delrin CNC machining black delrin
2011 SkillsUSA Washington Precision Machining Contest April 22, 2011, Washington State SkillsUSA Precision Machining Contest Every effort was made to include every contestant and every judge in this video. Hopefully, they are all there. (My sincere apologies if any are missing.) The contest was held at Perry Technical Institute, Yakima, WA. Contest hosts were Machine Technology Department Head Dan Steinmetz and Machine Technology Instructor Jason Wellner. Gold Medalist: Caleb Franett from Sno-Isle Skills Center and Arlington High School. Silver Medalist: Dylan Dunham from Sno-Isle Skills Center and Lake Stevens High School. Bronze Medalist: Thomas Williams from Port Angeles High School. Sno-Isle Skills Center Instructor: Tom Clemans Port Angeles Instructor: Mike Frick The precision machining contest is based on NIMS (National Institute for Metalworking Skills) standards for machining and manufacturing, and is a very rigorous contest. On Friday of conference week, the participants go through five 1-hour contest stations. The five stations are: . Manual milling machine . Engine lathe (manual turning machine) . Semi-precision layout and drill press . Quality control, workpiece inspection, blueprint interpretation . Machining theory written test For each section in which a machined part is made, points are awarded for each correct dimension. A part need not be completed in order to have one or more dimensions within the specified dimension tolerance. The allowed size tolerance for many of the dimensions is ± .005 (5/1000) inch ...
5Axis Machining cnc [www.disn.co.jp] 5Achs DMG/HyperMILL Daishin Seiki Corporation is a leading provider of prototypes to the motorsport industry and specializes in technologically sophisticated parts and 5-axis manufacturing. The Performance Racing Helmet was commissioned to celebrate Daishin Seikis 50th anniversary. This full face helmet won the gold medal in the prestigious Mori-Seiki Dream Cutting Contest 2009. This helmet will be on display in the OPEN MIND booth at the IMTS show in Chicago September 13-18, 2010. A brief interview with the CEO of Daishin Seiki, Mr. Ryosuke Omachi regarding this project is available at: www.openmind- 同時５軸加工 1/1 オリジナルヘルメット 株式会社 大槇精機 創業50周年記念モデル
CNC dental CAD/CAM machining with Wissner and WorkNC Dental Dental - teeth - implant machining. Wissner machine. WorkNC Dental CAD-CAM software by Sescoi
Sinker EDM Machining Sinker EDM Machining at EDM Technologies on a Roboform 35. For more information visit us at
VIBRA-FREE High Speed Aluminum Machining High Speed Aluminum Cutting, Thin Wall
CNC MACHINING OF A ROCKER CLAMP FOR A MILLING MACHINE CNC milling a side frame piece for a self adjusting rocker clamp used on a milling machine. These types of clamps can be used with either the milling table T-Slots or on a custom fixture plate as shown in video. The clamp is easily re-sized to suit most any milling table. Enjoy and thanks for watching!
Mini Machining Center - final design 4th axis - scratch built servo powered X2 mill with final design scratch built 4th axis doing multiple operations with one G-code program. 4th axis has sealed ball bearings pre-loaded by threaded collar and homing index moved to the rear and a robust motor mount. A new Rutex 2010 servo drive gets full speed and power from the motor, allowing use of a carbide insert with chip breaker . . no more long stringies! Speed is 400000 quadrature counts per sec, which is 3300 motor RPM. Spindle can run 2:1 or 3:1 (as shown) ratio. First pas is .062" or 1/8" off stock OD. Tested depth of cut (so far) is .080" aluminum and .060 Steel, limited by rigidity of the little mill. Part is a vacuum fitting for classic Corvette (GM Crossfire injection). Also still testing Youtube HD. This upload file is H.264 1080P 30fps. File size just under 1GB. Zooms are done in Adobe Premiere Pro CS3 and not by the Sony HDR-HC7 camera, so resolution reduces as zoom increases with interpolation done by Premier.
Abrasive Waterjet Machining Systems
Machining a Spur Gear A gear is made from bar stock to finished gear. Visit my other adventures at /Projects
Machining Sprockets for M18 using M24 Rubber Track Here in the video we first show us machining a sprocket half down to the correct diameter before installing the teeth. The second half of the video shows the half after the teeth have been installed. Here we are machining a 60 degree angle into what will be the inside middle of the sprocket half. This wedge is needed since on M24 track the track guides which run down the middle of the sprocket are angled.
ULTRIX 1000 - RIM MOULD HIGH SPEED MACHINING ULTRIX 800/1000 turns, mills and grinds in one set-up; with 5 interpolated axes turning table with diameter up to 1000 mm, loading capacity up to 2500 kg and turning spindle speed up to 800rpm. Ideal solution for Special Alloys (Titanium, Inconel), Steel, Aluminium, Composites and Resins machinings.
Cylinder Block Machining Video - Engine Building DVD Buy the "Basic Engine Building" DVD Basic Engine Building DVD - Chapter 25: Cylinder Block By this time your block is disassembled and in the machine shop. One of the most informative sections, here we take you behind the scenes to show what goes on while your away. We show the process of align honing the main bearing bore that is needed before anything else can be machined. Then the block deck is leveled and machined as needed for the new head gaskets to seat properly. And finally the cylinder walls are bored out just shy of their new size, which will be achieved when they're is a community and resource designed for automotive enthusiasts. The Basic Engine Building DVD is over three hours of engine building that covers everything from removal and disassembly to final assembly and engine start-up. This is the ultimate DVD for any home mechanic or engine enthusiast that wants to see a complete rebuild from Teardown to Start-Up. This video can be used to learn how to work on almost any type of internal combustion engine including V8, V6, Straight 8, in-line 6 and even 4 cylinder engines. All of the interactive features and menus will not work over YouTube. This video is great for people interested in car repair, car care, and restoration. As well as hot rods, muscle cars, performance parts, and boosting horsepower. It can also help you to gain knowledge for increasing fuel economy, how to lower your emissions, and covers preventative ...
big lathe ! big lathe machining 5 ton impact crusher shaft!
Fadal CNC Mill Machining Brass multi axis This is a video of one of our CNC mills running a limited production run on one of our new products.
CNC Stomp Pad 5 - Mach 3 G-Code - Learn CNC Plasma Cutting In this video we go through Mach 3 to look over the g-code. We are checking to see if we have any problems before we go to the CNC Plasma Cutter.
