Metalspun Products - Metal Spining & Hydroforming Metal spinning & fabrication projects: Metal Spinning: Hemispheres, Clyinders, Flanges, Shells, Cones, Cans, Lids Hydroforming: Pots, Floats, Filters, Lighting, Irregular shapes 2nd Operat.: Stamping, Fabrication, Machining, Anodizing, Shearing Lathe: Spinning Metal, Machining, Trimming, Beading, Flanging, Cornering, Burnishing
HydroForm-Ambient This is another in the Hydro-Form performance series.
HydroForm-Rocket Whale Video of the Hydro-Formed Rocket Whale performance at CUA and the making of.
Production Metal Bellows Hydro-Forming Machines - Model HFBH-9501-A
Interlaken Hydroforming Press System
FOES - Tube forming process FOES Tube forming process by cold press (mold)
A demonstration of Explosive hydroforming using oxygen and acetylene. This video shows just how tough rubber maid products are. Only reason tank split is because it was already damaged. Not very loud, the black tank is part of the vacuum system that displaces air in the target (female die) pulls it down to quarter atmosphere. I have the tank in line with my vacuum pump for two reasons; first any water hitting the vacuum pump will destroy it. The second is that the pump pulls vacuum too slow. The thing I call the hat holds the oxygen and acetylene mix. I was told that the pressure wave of the blast move about 25 meters per second.
Hydroforming,Hydroforming press,Hydroformed pipe,Shuz Tung WATER HYDRO-FORMING MACHINE DESIGNED TO FORM COMPLEX SHAPE WITH HIGH PRESSURE INSIDE TUBES. THICKNESS WILL BE KEPT THE SAME AFTER FORMING. USING WATER TO FORM TUBE FOR SAVING TIME TO CLEAN TUBES. MAX. HYDRAULIC PRESSURE: 210KG/CM2. MAX. CLAMPING FORCE: 600T MAX. HIGHT BETWEEN CLAMPERS: 380MM MAX. PRESS LENGTH: 280MM (BOTH SIDES) MOULD MOUNTING AREA: 1200X500 MM LOW PRESSURE FOR WATERING WITH VALUME 2.7L. ADOPTS WITH SERVO PRESSURE ADJUSTING VALVES AND PUMPS TO CONTROL FORMING SPEED. PROCESS: INSERT TUBE→CLAMPING→FORMING→PRESSURE KEEPING→PRESSURE RELEAING→TAKE OUT TUBE. ELECTRICITY CONSUMPTION: 160HP DIMENSTION (L x W x H): 6160 X 2400 X 5810 MM WEIGHT: 60000 KGS (NOT INCLUDING MOULD, OIL AND WATER).
HYDRO FORMING 7.62x39 IN TO 6.5MM GRENDEL.wmv
Hydroforming simulation Hydroforming simulation using Metafor FE software
Chumba Racing - Design, Research & Development, Hydroforming Chumba Racing - Design, Research & Development
Hydroforming of "I was, I am, I am to come" This is the "Fire Hydrant Hydroforming" process I use for my sculptures. Enjoy.
Productivity Inc Hydroforming Cell using RoboFlex Productivity Inc Hydroforming Cell allows complete machining of a part with no machine operator present. The system when fully loaded Productivity Hydroforming Cell allows complete machining of a part with no machine operator present. The system when fully loaded will run for 12-14 hours. It takes about an hour to unload, replenish, and service the machine. This can mostly be done while the equipment is in operation. Provisions were built in originally to allow a second machine and robot to this system which will allow twice as much output from the system without modifying the pallet transfer equipment.
Triform Sheet Hydroforming Fluid Cell Press Animation The Triform presses have been engineered using the latest technology. Modern design software, state-of-the-art hydraulics, and computer-driven controls provide the user with tremendous capability in an easy-to-operate package. The resulting hydroforming presses are offered in both Fluid Cell and Deep Draw configurations for use in a wide range of industries - aerospace, lighting, automotive, medical devices and more. Triform presses offer precision forming of a wide range of materials, with tooling cost savings of up to 90% through the elimination of mating dies.
Triform BD Sheet Hydroforming Press Portability The cost efficient Triform BD (seen in the video) from Pryer Technology Group () is a high performance alternative to Pad Forming. The reduced weight and height of the Triform Hydroform Press eliminates the need for special flooring, including expensive pits and foundations. It can be installed in a matter of minutes, creating parts with minimal setup. For more information, visit
Hydroforming PART 2 - Make Exhaust 2-Stroke ( PROTO RS 500 KTM ) justmylife.fr this is my exhaust home made
Hydro Forming attempt 3 1--20 ga sheet metal,2--pieces of 1/2" steel, butt load of 1/2" bolts, and 2800 psi pressure washer Semi successful with thinner sheet metal but not desired height
Hydroforming To learn more about how hydroforming works, visit or call us at 740-545-6381! "The hydroforming process, you set up your machine, get the tool out required for the job, locate your blanks, put your blank in and do a pre-charge, which is putting pressure on the blank to to hold it to the tool to start forming. Then you set your pressures to draw. You have a top pressure that controls a lot of your material thin-out. So then you start the draw process. Whenever you get to your top pressure, there's a displacement inside the chamber that allows the oil to dissipate so you don't build up anymore pressure. You draw up and set a high-limit for your draw, it'll kick the punch out when you achieve your total depth. Then you raise the dome and you strip your punch out and then take the part out of the press, and that's your process. This particular part was a very unique shape. There are intricate angles to it and working with a brass is a touch material to work with because when you draw it up, it work hardens, so then you have to do some work to it in order to be able to do some of the shapes we do, the forming we do to it. With hydroforming, you can draw the part up with pressure, you have pressure in the rubber diaphragm on top, that forms the material to the size and shape of the punch. Hydroforming is something that you can control your tolerances, and with hydroforming, your part can go through with a lot less scratching like you have with mechanical ...
Hydro forming attempt 1 1--16 ga sheet metal,2--pieces of 1/2" steel, butt load of 1/2" bolts, and 2800 psi pressure washer. Unsucessful but high hopes. Leaks
Sheet Hydroforming Process Animated view of Amino's Sheet Hydroforming process.
Hydroforming Technology: The latest in Black Diamond ice tool construction. We use hydroforming to make the shafts on our Viper and redesigned Fall 2009 Fusion ice tools. Watch this video of Climbing Hardgoods Manager Bill Belcourt as he explains the process and its advantages. Check out our full line of ice axes and piolets at:
Sheet Hydroform Production Sheet hydroform production run at Amino.
Hydroforming FE Simulation Hydroforming simulation using Metafor FE software
HydroForm-Untitled This is another in the Hydro-Form performance series. With A theremin added and other casting relics.
Triform Deep Draw Sheet Hydroforming Press Animation The Triform presses have been engineered using the latest technology. Modern design software, state-of-the-art hydraulics, and computer-driven controls provide the user with tremendous capability in an easy-to-operate package. The resulting hydroforming presses are offered in both Fluid Cell and Deep Draw configurations for use in a wide range of industries - aerospace, lighting, automotive, medical devices and more. Triform presses offer precision forming of a wide range of materials, with tooling cost savings of up to 90% through the elimination of mating dies.
Hydroform & Structural Frame Automation (Part 2) Wayne Trail Technologies is a recognized leader in the design and supply of flexible, automated systems for metal forming, metal fabricating and metal joining applications. The prinicple products and services we supply include press room automation; tube bending and fabricating systems; tubular...
Sheet metal hydroforming Hydroforming in action This video shows the progressive deformation of sheet metal using high-pressure fluid, or sheet-metal hydroforming. It showcases the advantages of Inoxveneta's hydroforming technologies with respect to traditional forming methods: uniform stretching with great flatness and consistent product geometry, excellent surface quality.
3D Systems ProJet Printer Hydroforming Tool. "Same Day Custom Metal Parts" ProJet Printer tool for same day tooling. Tool was built in 6 hours and showed no signs of wear after 100 pieces formed. This shows the application of same day turn around for custom formed metal parts. The printer could have built 6 different tools all in one 6 hour build for multiple custom formed parts with same day turnaround. www.3
Hydroforming PART 1 - Make Exhaust 2-Stroke ( PROTO RS 500 KTM ) justmylife.fr this is my exhaust home made
Hydroforming Washer Tub / SUTHERLAND This was machine tub come from coil steel, then welded before it enters the Sutherland Hydroform Press.
Hydroforming PART 3 - Make Exhaust 2-Stroke ( PROTO RS 500 KTM ) justmylife.fr this is my exhaust home made
ST5000/TL240 Hydro-Forming technology Samsungimaging Youtube channel Here're special features. - Samrt Gesture UI/Haptick feedback - TFT, 3.5inch Touch Screen LCD - Smart Filter(Advanced Filter Effects) - 7x Optical zoom - Smart Auto 2.0(Still&Movie) - Panorama shot - Not support sharing on web Get information about the newest review of Samsung cameras and camcorders.Learn more Samsung Camera/Camcorder,SUBSCRIBE! =-=-=-=-=-=-=-=-=-=-=-=-=-==-=-=-=-=-==-=-=-=-=-=-=-=-=-= # Playlist: Samsung Digital Camera Review =-=-=-=-=-=-=-=-=-=-=-=-=-==-=-=-=-=-==-=-=-=-=-=-=-=-=-= Thank you for watching!
Hydro Forming attempt 2 1--16 ga sheet metal,2--pieces of 1/2" steel, butt load of 1/2" bolts, and 2800 psi pressure washer Unsuccessful, still leaks too much
Hydroform & Structural Frame Automation (Part 1) Wayne Trail Technologies is a recognized leader in the design and supply of flexible, automated systems for metal forming, metal fabricating and metal joining applications. The prinicple products and services we supply include press room automation; tube bending and fabricating systems; tubular...
Triform Sheet Hydroforming Press - Open chamber feature During development, the operator has the unique ability to open the chamber at chosen points in the cycle in order to visually inspect the partially formed part. This allows the operator to target portions of the recipe potentially causing wrinkles or tears without much of the guesswork associated with ***yzing a fully formed part. Once the visual inspection is complete, the operator has the option to abort the cycle, to adjust subsequent recipe steps before continuing the cycle or to continue the cycle without making adjustments to the recipe. If continued, the chamber once again closes and the cycle is automatically resumed at the point (pressure and position) at which it previously opened. There are many more ways a Triform press can lower costs, including reducing or eliminating finishing and other labor costs. To view all the benefits that Triform Sheet Hydroforming presses can bring to your operation, just visit our website.
HydroFORM Calibration Watch how to find the calibration with our HydroFORM Scanner. Learn more about the product used at: bit.ly
