Maveric High-wind Launch Hand launch of a Maveric on a day with sustained winds of 20+ kts and much higher gusts.
Gimbaled Nozzle Interior Ankur/Florian's 6 axis IMU + radio, controlling the orientation of a rocket motor with respect to the rocket body.
India's Prithvi Air Defence (PAD) / Pradyumna Ballistic Missile Interceptor The Prithvi Air Defence (PAD) is an anti-ballistic missile developed to intercept incoming ballistic missiles outside of the atmosphere (exo-atmospheric). Based on the Prithvi missile, PAD is a two stage missile with a maximum interception altitude of 80 km (50 mi). The first stage is a liquid fuelled motor while the second stage is solid fuelled. It has maneuver thrusters which can generate a lateral acceleration of more than 5 gs at 50 km (31 mi) altitude. Guidance is provided by an intertial navigation system with mid-course updates from LRTR and active radar homing in the terminal phase. PAD has capability to engage the 300 to 2000 km (190 to 1200 mi) class of ballistic missiles at a speed of Mach 5. LRTR is the target acquisition and fire control radar for the PAD missile. It is an active phased array radar having capability to track 200 targets at a range of 600 km (370 mi). The PAD missile has also been called Pradyumna. Further development led to the improvement of the interception range to the 80 to 50 km (50 to 31 mi) range. The improved missile will utilize a gimbaled directional warhead, a technology that until now has only been used by the US and Russia. This technology allows for a smaller warhead to destroy the target missile. The PADE (Prithvi Air Defence Exercise) was conducted on November 2006 in which a PAD missile successfully intercepted a modified Prithvi-II Missile at an altitude of 50 km (31 mi). The Prithvi-II ballistic missile was modified ...
Maveric Autonomous Onboard Collision Detection with Overlay A demonstration of Prioria's onboard collision-detection technology integrated into the Maveric UAS. This video shows collision detection running with the collision warning overlay.
Bental mercava Bental Industries Ltd. is renowned for its ability to design and manufacture reliable, high performance, high precision Motion Systems and sub-Systems that operate on the most challenging conditions. Since 1983 Bental Industries has been supplying Electro-Mechanical Solutions for the Defense, Aerospace and Industrial markets. Bental's team is comprised of 130 employees, among them, more than 30 high skilled and experienced R&D Engineers that are familiar with various types of Motors, Servo Actuators, PMGs (Permanent Magnet Generators/Alternators), Electronic Drivers & Controllers, Stabilized Gimbaled Systems and Complimentary Systems. Our team is mostly experienced in the Custom-Made and Built to Spec Systems. For more than 20 years, Bental Industries has been serving major companies in the defense and aerospace industries in Israel, overseas, and have achieved worldwide recognition for the reliability and performance of its products The engineering team is composed of Electro-Mechanical, Electronics and Mechanical engineers. This team specializes in products which are Designed to Meet the Challenge in terms of quality, reliability and robust performance. Quality control and inspection is carried out through all steps of design and production. Bental is a certified ISO-9001-2000 supplier.
Maveric Click-tracking a Car Pulling Off the Road Utilizing the retractable gimbaled camera on the Maveric from an altitude of 300 ft, a car is tracked while driving and pulling off the road.
Night Time Gimballing A-1 Test Stand A close-up view of a Space Shuttle Main Engine during a night test at Stennis Space Center shows how the engine is gimbaled, or rotated, to evaluate the performance of its components under simulated flight conditions. Credit:NASA/Stennis
How to Choose the Right Fiber Optic Gyro: Introduction to Gyros (1 of 13) This KVH precision fiber optic gyro overview explains how gyros are used for stabilization, guidance, navigation, and precision pointing applications for cameras, radar, optical sensors, antennas, weapons, and unmanned vehicles. For more information, please visit us at and http
Turtlehead Peak (up) Red Rock Canyon Las Vegas, Part 1, TP1win A difficult "video-hike" up to Red Rock Canyon's Turtlehead Peak: I tried, but after mile 2.1 near hurricane force winds made it all but impossible to continue on up to the peak. Still, it was an invaluable experience and an important test I needed to do and see how my camera set-up performs in (extreme) high winds. The result was very satisfactory and not much additional shake was detected. It was however difficult at times to hold and aim the camera and keep my own balance. Once and for all, it has assured me that it is very doubtful that ANY floating or "gimbaled" steadying camera equipment could work here. Such would be too heavy, too awkward (counterweights) and mostly uncontrollable in high winds. Part 2 takes you back down again. Use TP1win in SEARCH to find the clip again later.
Testing Rig Mark I Just some testing with our first iteration of the third person point of view rig. Note the swaying of the gimbaled camera mount. For more information, visit our instructable!
Model Rocket Gimbaled Nozzle
31" Disney Nautilus R/C conversion This is a video of my conversion of a static display model of the Disney Nautilus from 20000 Leagues Under the Sea to R/C operation. The unit has a fully functional gas ballast system and a custom-made gimbaled prop assembly for pitch control without the need for dive planes. Buy your own at !
Maveric Autonomous Onboard Collision-detection Operation A demonstration of Maveric's onboard autonomous collision-detection in operation. This video shows autonomous avoidance and switching between the forward-look and gimbaled cameras.
Southern Straits 2009 - me Babbling I kept this clip separate from main Southern Straits vid - it's just me groggy and babbling after waking up from an hour in the bunk. I made three mugs of Earl Grey (w/ cream and sugar!!!) which all 13 crew shared up and down the rail. It doesn't look like it, but I consider the success of producing 3 mugs of tea in these conditions as nothing short of miraculous!
Hermes 450 UAS by Elbit Systems Elbit's Hermes 450 UAS (Unmanned Aircraft System) A major player in Israels ongoing security activities, the Hermes® 450 is the Israeli Defense primary UAV system. The versatile, long-endurance UAV, equipped with Elbit Systems CoMPASS EO/IR/LD gimbaled electro-optical payload, can adapt to a wide range of payloads, including SAR/GMTI radar and dual payload configurations. Hermes® 450 executes its diverse missions in a highly autonomous manner and is controlled by the Hermes® Universal Ground Control System (UGCS), facilitates highly automated mission operation and control of the air vehicle and EO/IR/LD payload. The UAV is equipped with sophisticated communication systems transmitting imagery in real time to ground stations. Selected as the base line for the UK WATCHKEEPER program, Hermes® 450 is recognized as the leading long endurance tactical UAV in its class, having flown in US operations and history-making flights in UK civil airspace. To date, the Hermes® 450 has accumulated more than 65000 flight hours. The Hermes® 450 B is the version for the UK Watchkeeper program, with all weather capability, ruggedized structure and dual electro-optics and GMTI/SAR payloads.
McIntosh showcases MT10 Turntable The McIntosh MT10 Turntable marries classic McIntosh glass front panel cosmetics with serious mechanics to create a unique, ready-to-play LP solution. With tracking force, anti-skate and cartridge position preset at the factory, the McIntosh MT10 delivers high performance LP playback with minimal set up. A custom tonearm features a rigid, dural-aluminum arm-tube gimbaled in two sapphire (horizontal) and two ceramic (vertical) bearings for the least possible friction. A .5mV moving coil cartridge is included, and features an ebony body with an ellipitcal stylus. Visit for more information.
Maveric Click-tracking a Turning Car Utilizing the retractable gimbaled camera on the Maveric, a car is tracked through a turn from an altitude of 300ft.
Maveric Prone Launch Launching a Maveric while laying down.
Gimbaled Stove Demo in a Nonsuch 30U Here ya go Eddie. Gimbaled Stove Demo in a Nonsuch 30U. The clanging racket is the pots and pans banging around in the oven.
AeroVironment Puma AE UAS Puma AE (All Environment) is a small Unmanned Aircraft System (UAS) designed for land based and maritime operations. Capable of landing in the water or on land the Puma AE empowers the operator with an operational flexibility never before available in the Small UAS Class.
Camera Stabilizer Redux New video compares no stabilizer with solid iron pipe stabilizer and fully gimbaled stabilizer. Gimbaled stabilizer wins due to huge weight advantage.
Wireless Control of Gimbaled Camera Bottom line: Wiimote used to control gimbaled camera platform. Context: Proof of concept for: RF modem command and data handling, audio-video wireless transmission Some Wireless Details: --Wiimote sends data to laptop via bluetooth connection --Wiimote data processed using WiiYourself library () and translated into commands --Commands transmitted from PC to Arduino Diecimila via SparkFun RF modems () --Arduino issues commands to gimbal platform using pulse width modulation Some Hardware Details: --Video system procured through RangeVideo () --Camera used: KX171 --Video transmitter: 100 mW, 900 MHz --Gimbal platform: LynxMotion pan & tilt kit BG Music: "Gyakuten Saiban ~ Court Begins Blue note scale" // Gyakuten Saiban Meets Jazz
A Poor Man's Gimbaled Camera Steadying Mount Ingredients: A gimbaled cup holder from Cabelas, a long bolt with threads matching camera mount threads, a few large, heavy washers and a Tachyon XC helmet cam (or any camcorder or video cam that's small enough to fit.) The bolt fits through the washers, up through the bottom of the cup holder and screwed into the bottom of the camera. A small piece of foam pipe insulation is used as spacer under camera. The washers act as a counter weight, keeping the camera upright. The cup holder is mounted onto the rail of the boat and, voila! The poor man's gimbal camera mount!
Skylark I-LE UAV by Elbit Systems The mini UAV is quickly assembled before the mission and is launched by hand. Recovery is performed by a deep stall maneuver, which lands the vehicle safely on a small inflatable cushion, at a pre-designated point. The cushion is designed to protect the payload on landing. The entire mission is flown autonomously, feeding real-time continuous video and telemetry data to the portable ruggedized ground station. Its wingsSkylark 1 LE Mini Unmanned Aerial vehicle (M-UAV) Photo: Elbit Systems and tail surfaces are constructed of a lightweight composites, the fuselage tubular boom is also made of composites. The avionics and payload systems are contained in a pod carried below the boom. The gimbaled payload utilizes a daylight CCD or an optional FLIR for night operation, which can be rotated by four gimbals. In February 2004 Elbit won an IDF Ground Forces Command contract to supply the Skylark for evaluation and testing as an organic UAV system, to be operated by infantry units. Skylark has since entered operational service with selected IDF units, used for operational testing and doctrine development and evaluation. During the Second Lebanon war in July-August 2006, Skylark mini-UAVs were operated by IDF units performing close-in reconnaissance missions in support of the ground forces, providing valuable real-time intelligence, due to their low acoustic and visual signatures, Skylarks were able to operate at very low altitude practically undetectable. Skylark I mini UAV (early ...
Wireless Gimbaled Camera: Blimp Deployment Bottom line: Wiimote used to control gimbaled camera platform mounted on helium blimp Context: Proof of concept for RF modem command and data handling, audio-video wireless transmission Highlights: If you can see it, enjoy the views of Westwood and UCLA from above the Court of Sciences Apologies: The video cable from the camera was damaged during the set-up/deployment, so the video cuts out intermittently. Also, I borrowed a TV tuner without figuring out how to get decent recordings. Sorry. Some Wireless Details: --Wiimote sends data to laptop via bluetooth connection --Wiimote data processed using WiiYourself library () and translated into commands --Commands transmitted from PC to Arduino Diecimila (arduino.cc) via SparkFun RF modems () --Arduino issues commands to gimbal platform using pulse width modulation --Blimp controlled by RC transmitter/receiver pair Some Hardware Details: --Blimp is ~14 ft long, ~5 ft wide, ~250 cu ft volume --Video system procured through RangeVideo () --Camera used: KX171 --Video transmitter: 100 mW, 900 MHz --Gimbal platform: LynxMotion pan & tilt kit Location: UCLA Court of Sciences, Engineering Week 2008 Shout-outs: Thank you to Jon, Matt, Shatto, and Ann for their support. Thank you also to UCLA AIAA (aiaa.seas.ucla.edu) for giving me the resources needed to reach this stage of the project. BG Music: "Leisurely Brows" // Age of Empires 3 Soundtrack // Ensemble Studios
BYU MAGICC Lab: UAV Target Localization Footage from preliminary results from a UAV localizing a target using custom control and tracking software and a custom two-axis gimbaled camera system developed by Brigham Young University.
Dave Hein's Quad Pod II Dave Hein's Experimental gimbaled rocket
Handheld, multi-axis camera stabilization device utilizing MEMS gyro sensors (stabilizer) Handheld, multi-axis camera stabilization device utilizing MEMS gyro sensors (stabilizer) (US Patent 7642741, additional patent pending) In the field of motion picture photography, camera stabilization devices are used to isolate the camera from the natural body movements of the operator, while providing fluid maneuverability across a set. The purpose of this project is to design, build and optimize a low cost, compact gyro-based servo stabilization device for a professional handheld motion picture camera. This device uses MEMS based rate gyro sensors mounted to a gimbaled camera rig to measure the angular rate of the camera's rotation. The gyro signals are amplified to drive DC servo motors coupled to the camera's rotational axes. As a gyro measures the cameras rotation about an axis, the corresponding servo motor applies an opposing torque on the platform to oppose camera rotation. The camera is mounted to a yaw and pitch gimbaled structure, adjustable so that the rotational axes can run through the cameras center of mass, thus minimizing the torque and power required to stabilize the camera. Each gyro rate signal is amplified by a proportional gain amplifier. An integrator circuit acting on each rate signal, helps ensure that the rig does not drift due to extraneous forces. A pair of high current, high power operational amplifiers drive each servo motor from the sum of the proportional and integrated rate signals. Dynamic tests confirm that the gyro stabilization ...
PTZ EMCCD camera day night pelco 10km 8km 12km Long range IR color Long range IR cameracolor PTZ camera day night pelco 10km 8km 12km Long range IR color PTZ 1 2 3 4 5 6 7 8 9 10 12 15 20 25 miles km Camera Ranges Distance 1km 2km 3km 4km 5km 6km 7km 8km 9km 10km 12km 15km 20km Night Vision camera, Day Night 12.5-750mm/25-1500mm, 30-750mm, Night Vision/Thermal Detection equipment, Night Vision Long Range Devices, Digital Night Vision Viewers, Laser Rangefinder, Specials, Very useful Accessories,long range wireless Video ,solutions, camera, military ,System integrator,vidoconference,Questar,night vision,Export,telemedicine, long range, Eagle Vision,EV3000,fiber optic, control room, long, lens, thermal, day, night, 360 degree United vision, image transmission systems and integrated vehicle systems for military, police, emergency services and intelligence applications specialize in Border surveillance incorporating thermal imagers, cameras and real time links.And, of course, low, reasonable prices and excellent, professional, Long range IR color PTZ Thermal camera offshore tower Camera day color night GenIII Night Vision EMCCD surveillance boat tower mast wireless Target tracking Thermal 1 2 3 4 5 6 7 8 9 10 12 15 see 20 25 miles km PTZ army TCP/IP Target acquisition and continuous surveillance using UAV aircraft and gimbaled cameras. electro-optical sensor gimbal UAV aircraft control gimbal target position Tracker system Roll & Pitch Stabilization 2-3 knots specialized cameras,
2 Axes Gimbal Mount - Newmark Systems 2 Axes Gimbal with high accuracy angular encoders. Made in USA
Maveric Click-tracking a Moving Target Utilizing the retractable gimbaled camera on a Maveric, a moving target is selected and followed.
Mini-z mr 03 gimbaled motor mount
Loopa Gyroscopic Toddler Bowls from ThinkGeek This little bowl is weighted and gimbaled to rotate in all directions, so your little one won't spill a single thing.
Maveric Click-tracking a Stationary Target Utilizing the retractable gimbaled camera on a Maveric, a stationary target is selected and followed.
News Helicopter with High Definition & night vision Cameras Close look at a Broadcast News Bell 206 Helicopter equipped with High Definition (HD) gimbaled Camera and night vision camera - NAB 2008 Las Vegas NV TilTul delivers unique search of websites' names based on their popularity with TilTul Users. see:
Perplexus Gargantua Here is a large gimbaled working model of Perplexus Original. built for the American International Toy Fair at the Javits Center, New York City, February, 2011.
non-contact manipulation (gimbaled air jet control) interesting tech
14x40 Techno-Stabi Image-Stabilizing Binoculars 100% waterproof, high power binocular with image stabilization gives you rock steady images even while you're moving On water, land or through the air, these high power binoculars provide image stability. Even at 14X magnification, Fujinons Techno-Stabi provides a steady view of moving objects. Two direct-drive motors controlled by piezo vibration sensors stabilize the optics, rather than the binocular body. Image stabilizing prisms are mounted in a dual gimbaled frame Magnification - 14 power 100% multi-coated optics and phase-coated prisms Eye relief - 13mm Dimensions - 7.3" wide x 5.8" deep x 3.4" high Weight - 2.7 lbs. (31oz) Batteries - uses 4 AA batteries for up to 3 hours continuous use Provided with a hand strap Comes in a waterproof, airtight Pelican carrying case An optional 1228V DC external power source is available
Tacking a Scot - Gimballed Camera Joe Brake & Tricia Batchelor demonstrat roll tacking. Used gimbaled camera
Electro Telemaster footage RC flying with VR head tracking, Toowoomba
Palisades Top Industry Practice Award Entergy Nuclear employees at Palisades Power Plant took home the highest honor at the Nuclear Energy Assembly in the annual Top Industry Practice Awards. Entergy's Palisades team was the maintenance category winner and also earned the top honor, the B. Ralph Sylvia Best of the Best Award, over 14 other category winners at the meeting held in San Francisco by the Nuclear Energy Institute. The coveted Top Industry Practice awards rank among the nuclear industry's most prestigious recognitions. The employees won for developing a new instrument called a gimbaled head for inspections of the reactor vessel. Working with the vendor AREVA, this team innovation is one that will also be used across the industry since it vastly improves data collection for this important maintenance inspection. "We are very proud of our Palisades employees and their persistent spirit in building this device over a number of years until it resulted in a breakthrough advance for Entergy that ultimately now benefits the entire industry," said Entergy Nuclear president and CEO, John Herron. Herron also serves as the Chief Nuclear Officer for the Entergy Nuclear fleet, the second largest nuclear fleet in the US operating or providing management services to facilities in Arkansas, Louisiana, Massachusetts, Michigan, Mississippi, Nebraska, New York and Vermont. What is a gimbaled head? The gimbaled head performs inspections on the inside of the reactor head around the mechanisms that lift and lower control ...
Forespar Mini Galley Gimbaled Stove The Mini-Galley® Hot-Spot is a compact, versatile, fully gimbaled marine stove. This modern, attractive unit includes a low profile mounting bracket which allows the entire stove to be easily detached and stowed when not in use. It features an all stainless steel gimbaled "basket" with springs that secure the cooking pot. The Mini-Galley® Hot-Spot allows cooking under adverse weather conditions in the ***pit or below. The burner can be turned off and on instantly with no preheating or priming necessary. It is ideal for any yacht - sail, power, racer or cruiser.
