Dovetail jig My old style dovetail jig. Makes a compound joint. This jig still references from the end of the timber. The new jigs do not.
Rob Cosman's 6 1/2 Minute 1/2 Blind Dovetail Following up on the success of his 3 ½ minute thru dovetail you can now watch Rob cut a ½ blind dovetail in under 7 minutes. Produced by , © 2010
How to cut Dovetail Joints by hand Dovetails hand cut by John Bullar from Furniture & Cabinet Making magazine Video in HD
Dovetail Woodcraft Allentown has classes on the Porter Cable Dovetail Jig
Chestmate Dovetail Jig Chestmate allows you the freedom to create your own custom, variable or fixed-space dovetail patterns on any width stock. Make dovetails on 1/2" to 1" thick wood simply by cutting slots in a guide board which is then used for indexing. The guide board serves as a backer board and can be reused for future projects. The pin guide is adjustable to fine tune the dovetail joint fit. Kit includes dovetail jig, indexing guide, pin guide and detailed instructions. Please note; Chestmate requires the use of the following popular router accessories: a 5/8" x 1/2" template bushing which fits in any 6" diameter router base, a 3/4" 14° dovetail bit to cut the tails and a 5/16" straight bit to cut the pins, all sold separately. This kit works great with dovetail bits 134-1205 or 134-0805 and straight bit 102-0562.
Leigh Super Jigs Half-blind Dovetails Rout variably spaced Half-blind dovetails on all Leigh Super Jigs
Rockler Complete Dovetail Jig Cutting beautiful through and half-blind dovetails is fast and easy with our new and improved dovetail jig. This is our best and most versatile dovetail jig ever!
Leigh D4R Half-blind Dovetails A complete guide to routing perfect Half-blind Dovetails on the Leigh D4R Dovetail Jig
122- Hand Cut Half Blind Dovetails Guild members will remember this small excerpt from the Shaker Table series. Its just a taste of some of the fun we have in the Guild. Sign up now and get 15% off your membership. Dovetails: very few joints are held in such high regard. Not sure why exactly, but there seems to be a nearly universal love and adoration for this flying vermin-inspired interlocking joint. And I don't care what anyone says, doves are just dirty pigeons in a lighter-colored outfit. To be fair though, the joint is beautiful, incredibly strong, and requires skill and attention to detail to cut by hand. One of the most common variations of the dovetail is known as a half-blind dovetail. You'll find this joint most often on drawer fronts where you don't necessarily want to see the joint from the front. With a few tools, a little know-how, and a lot of patience, this beloved joint is well within your grasp. And speaking of patience, what's the rush people?!?! It seems like some folks feel that if they aren't cutting their dovetails in three minutes, they aren't doing it correctly. I say put the breaks on and enjoy the process. After all, isn't that why you're cutting them by hand? If I wanted them cut in just a few minutes, I'd keep a dedicated jig set up and knock them out with my router. Take your time.....be one with the wood......
Dovetail Joint - Level On The Inside You sit me down To explain All the trials you've endured Around and around The refrain Rings the same each time it's heard Entertain the notion Entertain the notion That the only thing I hear Is the crack of a smile In a face That ain't so sincere When I'm measuring out your quality It is only as deep as your modesty As your insides fall to pieces Shattered by the silent treatment Things are only fragile 'til they break Feigning your humility It only serves to weaken the Most common observations that you make Drown me out in conversation Surf a wave of provocation Wash away my interest in your wake I think you can Reach a place Where the impetus is pure You'll understand A disgrace Is the thing that makes us feel Level on the inside Level on this outside I'm content to know it Level on the inside (level on the outside) Level on the outside I don't need to show it
MLCS Woodworking Through Dovetail Templates A detailed demonstration on how to setup and use two different Through Dovetail templates by MLCS Woodworking. Get great looking dovetail joints for a small investment. This easy to use dovetail system can produce dovetails on any width board. You can even make variable spaced dovetails!
Handcut Dovetails HD This is not the fastest way to cut dovetails by hand, but it is accurate, due in part to the use of a guide block. Read the write-up at
Jointmaker Pro - Cutting Dovetails - Bridge City Tool Works An instructional video on how to cut dovetail joints on the Jointmaker Pro by Bridge City Tool Works
Frank Klausz, "Dovetail A Drawer" DVD intro Frank Klausz Dovetail a Drawer by hand A preview taken from TAUNTON (c) DVD
Leigh D4R Sliding Dovetails Rout sliding dovetails on the Leigh D4R Dovetail Jig
Handcut Dovetails A quick video on handcut dovetails
Laguna Tools - Dovetail Machine The New Laguna Platinum Series Automatic Dovetail machine creates perfect dovetail joints effortlessly at a production rate of approximately 40-50 boxes per hour. Dovetail joints are widely recognized as one of the strongest and most durable joints in woodworking and add value to your cabinet jobs. This machine cuts the pins and tails separately or at the same time to speed up production. Individual pneumatic clamps allow users to cut two joints in one pass or to work on wide panels for furniture. The collet chuck makes bit changes quick and easy and increases cutter life. Adjustments are read on individual scales for quick, repeatable set-ups. The centralized control panel makes operation easy and automatic, the operator just needs to load the parts and start. This machine is sure to increase your profits and productivity.
EZ-Pro Dovetail Jig from General Tools (Part 2 of 2) Part 2 of 2 How to use the new EZ-Pro Dovetail Jig from General Tools & Instruments. • Makes Through Joints and Half-Blind Joints. • Easy to use for the beginner as well as the professional woodworker. • Self-aligning design ensures that both ends of the dovetail joint will match up evenly every time. • Portable design lets you bring the jig to your work piece. • Sturdy machined aluminum construction. • Easily adjust the dovetail interference to create loose or tight joints. • Jig is free standing - no need to bolt it to a workbench. • Integrated clamps allow precise clamping of the jig to your work piece. • No assembly required. • Accommodates boards of any width. • Includes one 14 degree 1/2" Dovetail Router Bit. For more info, visit:
Rob Cosman's Dovetail Saw Rob describes the first of his hand saw offerings, the dovetail saw. After teaching thousands of folks to cut dovetails by hand, Rob has tailored a saw to address the most common problems. With the intent to enable woodworkers to assemble their dovetails straight from the saw this may very well be the missing link! Produced by , © 2009
EZ-Pro Dovetail Jig from General Tools (Part 1 of 2) Part 1 of 2 How to use the new EZ-Pro Dovetail Jig from General Tools & Instruments. • Makes Through Joints and Half-Blind Joints. • Easy to use for the beginner as well as the professional woodworker. • Self-aligning design ensures that both ends of the dovetail joint will match up evenly every time. • Portable design lets you bring the jig to your work piece. • Sturdy machined aluminum construction. • Easily adjust the dovetail interference to create loose or tight joints. • Jig is free standing - no need to bolt it to a workbench. • Integrated clamps allow precise clamping of the jig to your work piece. • No assembly required. • Accommodates boards of any width. • Includes one 14 degree 1/2" Dovetail Router Bit. For more info, visit:
Rockler Dovetail Jig Combo Review A video review showing the features and use of Rockler's Dovetail Jig Combo.
Leigh D4R 24" Dovetail Jig This video is from the full-length review of the famous Leigh D4R Dovetail jig on at the link below. This review includess a look at their hyper-effecive dust collection system for dovetailing. A few years ago I never would have thought it possible to improve their D4 dovetail jig but they have made the gold standard "golder". See the full review for all of the details.
CNC Dovetailing Machine - Omec F11 www.machines4 CNC Dovetailing Machine - Omec F11 The CNC-operated F11TS milling machine has been designed to guarantee maximum versatility in the machining of drawers and furniture parts. The machine is controlled by a CNC system that is programmed to give maximum machining flexibility and enables operators to modify the following parameters (within machining limits): type, pitch, number and depth of joints, work-piece size, cutting speed, tool feeding speed and compensation of tool diameter variation. All machining data are easily entered by simple instructions displayed on the machine monitor. The CNC system can save up to 600 different machining programmes that can be recalled according to the operator's needs. The graphical interface of the machine software is based on dropdown menus and is designed to load programmes directly from the bar code scanner.The machine output is 120 complete drawers per hour. For more information - visit our website www.machines4 or contact us directly Scott & Sargeant Woodworking Machinery Ltd Blatchford Road, Horsham, RH13 5QR ENGLAND Tel +44 (0) 1403 273000
Creating a dovetail joint with hand tools Lie-Nielsen Toolworks, Inc, which designs, manufactures and sells a wide variety of woodworking hand planes and tools, held 2 days of interactive demonstrations in the Building Construction Technology's area during January 2009. This demonstration, presented by the Homestead Heritage School of Woodworking, shows how to make dovetail joints by only using hand tools.
Trend DC400 Dovetail Jig www.trend- The DC400 is the world's first totally variable layout dovetail jig that is completely free of complicated set ups, offsets and adjustments! You can go from through dovetails to lapped dovetails, switch between pins and tails, change work piece thickness, cut rebated drawer fronts and vary the pin angle, all without adjustment to the jig. A combination of ground-breaking engineering, 'all aspects covered' geometry, distortion free parallel clamping and a remarkable full repeat feature, have together produced the greatest advance in dovetail machining since the hand held router was developed. The jig is ready to work straight from the box, minimal setting-up required. You will have finished your project while others are still puzzling over how to use their jig! Visit our website for comprehensive information on the entire Trend range and details of your nearest stockist.
ShopBot Cutting Dovetails ShopBot PRSalpha cutting dovetails in hard Maple drawer sides
Router Dwr Dovetail 1 Part 1, Note: The difficult part, setting the depth on the router bit, is already done before this lesson starts. Also, the stops on the older model Porter Cable dovetail jig are set and a jig is provided. This lesson shows how to cut the Dovetails into the Drawer Face and Sides of the lower drawer for the Router Table's box.
Rob Cosman's 3 1/2 minute "Tails 1st" dovetail Watch as Rob cuts a "Cabinet grade" thru dovetail in 3 min 40 seconds! Visit for more tips, tools, and information. Produced by , © 2009
Easy Dovetails by Hand Dovetail joints video by John Bullar with basic hand tools - just a saw and chisel.
Trend DC400 Dovetail Jig - Drawer www.trend- Shows the full potential of the DC400 Dovetail Centre and provides a step by step guide for the construction of a simple drawer. Using both through and lapped dovetails, you will quickly appreciate just how fast and simple the Trend DC400 is to use. When using the DC400 in your workshop, the increase in productivity over conventional jigs will astound you. Visit our website for comprehensive information on the entire Trend range and details of your nearest stockist.
XS Sight Dovetail Installation - Pistol Pistols with front and rear dovetail sights, ie: Sigs, some 1911's, some Kahr's.
Dovetail Routing A cracking little five min epic to help you with your practical work.
Omec 450 Dovetail machine - Scott & Sargeant UK Omec 450 Manual Dovetail machine - The Omec 450 is an ideal low cost manual machine for making dovetailed drawers & decorative joints. This dovetailer can produce up to 20 drawer boxes/hr. The cam clamping assures secure holding pressure for the parts to be machined. The spindle floats on linear bearings minimizing both operator effort & error. The eccentric cutter is easily adjusted to attain exact joint fit. Male and female joints are cut simultaneously. The machine has an adjustable pitch bar allowing you to easily produce 4 different size joints. For more information - visit our website www.machines4 or contact us directly Scott & Sargeant Woodworking Machinery Ltd Blatchford Road, Horsham, RH13 5QR ENGLAND Tel +44 (0) 1403 273000
Hoffmann X-20 Dovetail Machine The Hoffmann X-20 bench - top routing machine is equipped with a high speed router motor, located at the center of the machine. The supplied 45 degree fence plate, which is guided in a keyway in the machine table, is used to accurately position the material on the table. Hermance Machine Co. phone - 570-326-9156
Dovetail joinery made easy Cutting dovetail joints with the Gifkins Dovetail Jig. Dovetailing has never been this easy! Roger cuts 4 joints for a small box using a table mounted router. This is chapter 3 from our demonstration DVD. For more info go to .au
Leigh Isoloc Hybrid Dovetail Templates A detailed description of Leigh's unique Isoloc Hybrid Dovetail templates and the fancy dovetails they produce.
Woodcraft Presents Cutting Dovetails With The AKEDA Dovetail Jig This video demonstrates using the AKEDA dovetail jig to take your projects to the next level.
Dovetail Homes work at Habitat for Humanity Dovetail Homes (a local Denver construction & remodel company) sent everyone to work at Habitat for Humanity's job site at: 1015 S Patton Ct., Denver, CO - Everyone including the President, Partners, Office Staff, managers, etc.
Dovetails Furniture joinery and food
Trend CDJ300 Dovetail Jig www.trend- Using dovetail joints when constructing drawers provides inherent strength and will always give an elegant professional look to a furniture project. Using a dovetail jig enables those new to routing to produce professionally made furniture without the need of traditional skills, but by using the versatility of their router. Designed to make it easy and affordable for any router owner to create dovetails for their projects with an easy to use jig at an economical price. The range of accessories is extensive and so enables an easy to use jig to be converted into a complete jointing system for a wide range of jointing solutions. Of particular interest to traditionalists will be the optional through dovetail templates. Out of the box, Trends dovetail jig has been designed to rout both cuts for perfect fitting lapped 1 dovetail joints in one operation with minimal setting up. The jig will adjust to cater for materials from 12mm to 25mm in thickness and include both the cutter and the guide bush. Square steel clamping bars firmly grip the material against offset stops to ensure accurate cuts are made. The body of the jig is a welded steel construction, the templates are zinc plated steel with laser cut fingers. Optional templates are available. Visit our website for comprehensive information on the entire Trend range and details of your nearest stockist.
